1
17121-130-640
CLAMPER, FUEL TUBE
*
2
CLAMPER, FUEL TUBE
*
3
30530-087-711
COIL ASSY., IGNITION
*
4
30700-KE2-942
CAP ASSY., NOISE SUPPRESSOR (NICHIRIN)
305:-
5
31502-086-017
BAND, BATTERY MOUNTING
110:-
6
31700-124-008
RECTIFIER ASSY., SILICON (STANLEY)
505:-
6
31700-124-008
RECTIFIER ASSY., SILICON (SHINDENGEN)
505:-
7
32100-090-700
HARNESS, WIRE
*
8
32105-086-000
HARNESS, SILICON SUB WIRE
*
9
32106-437-300
CONNECTOR A, FUSE (YUASA)
75:-
10
32112-041-008
CONNECTOR B, FUSE (YUASA)
55:-
11
STAY, SILICON RECTIFIER
*
13
35030-086-010
SWITCH KIT, COMBINATION
*
14
35100-086-047
SWITCH ASSY., COMBINATION
*
17
38110-086-721
HORN ASSY.
*
18
BRACKET, HORN
*
18
BRACKET, HORN
*
19
38300-070-405
RELAY ASSY., WINKER
*
22
38306-292-000
SUSPENSION, WINKER RELAY
55:-
23
38307-090-700
STAY, WINKER RELAY
*
24
50373-040-020
BAND, BATTERY
*
25
50381-040-010ZA
PLATE, BATTERY SUPPORT
*
26
92101-060120A
BOLT, HEX., 6X12
20:-
27
92301-060160A
BOLT, RECESSED, 6X16
35:-
28
93402-0601200
BOLT-WASHER, 6X12
30:-
29
93403-0601600
BOLT-WASHER, 6X16
35:-
30
93500-060120A
SCREW, PAN, 6X12, åtgår 2st
1251:-
31
93891-0602200
SCREW-WASHER, 6X22
*
31
93891-0602000
SCREW-WASHER, 6X20
*
32
94001-062000S
NUT, HEX., 6MM, åtgår 2st
1251:-
32
94050-06000
NUT, FLANGE, 6MM, åtgår 2st
15:-
32
94070-06080
NUT-WASHER, 6MM, åtgår 2st
10:-
33
94101-06000
WASHER, PLAIN, 6MM, åtgår 2st
10:-
34
94201-30450
PIN, SPLIT, 3.0X45
10:-
35
95014-61300
BAND A3, WIRE
25:-
36
98200-10700
FUSE (7A), åtgår 2st
15:-
37
31500-437-752
BATTERY, 6N4-2A-4
195:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
