1
13491-283-000
RING
82:-
2
13492-283-000
RING
50:-
2
95015-25200
RING,SET,520
50:-
3
23100-323-000
SHAFT,PRIMARY
*
4
23102-323-000
PLATE,BEARING SET
*
5
23103-374-000
GEAR,PRIM.DRIVE
*
6
23105-323-000
COLLAR,22X13.6
*
7
23111-323-010
SPROCKET,PRIMARY
*
8
23114-323-000
RUBBER,PRIMARY, åtgår 8st
80:-
9
23121-323-010
HUB,PRIMARY DRIVE
*
10
23131-323-003
CHAIN,PRIMARY
2010:-
10
23131-426-003
CHAIN,PRIM.DRIVE
2010:-
11
23210-374-000
SHAFT,TRNS.MAIN
*
12
23220-374-000
SHAFT,TRNS.
*
13
23420-374-000
GEAR,CT/SHAFT.LOW
*
14
23431-374-000
GEAR,M/SHAET
*
15
23441-286-020
GEAR C2
*
16
23451-374-000
GEAR (28T)
*
17
234A1-390-305
GEAR SET,C3.C4
*
17
234A1-390-315
SHAFT,GEAR SET
*
17
23461-286-030
(234A1-390-315) GEAR C3
*
17
23471-286-010
GEAR (29T)
*
18
234A1-390-305
GEAR SET,C3.C4
*
18
234A1-390-315
SHAFT,GEAR SET
*
18
23471-286-010
GEAR (29T)
*
19
23481-374-000
GEAR (30T)
*
20
23491-374-000
GEAR,CT/SHAFT.TOP
948:-
21
23801-300-010
SPROCKET,DRIVE
*
22
23811-292-000
PLATE,FIXING
35:-
23
23931-323-004
NEEDLE BRG
528:-
24
24211-374-000
FORK,R.GEAR SHIFT
666:-
25
24212-374-000
FORK,C.GEAR SHIFT
*
25
24212-390-000
FORK,C.GEAR SHIFT
834:-
25
24212-390-000
FORK,C.GEAR SHIFT
834:-
26
24213-374-000
FORK,L.GEAR SHIFT
666:-
27
24261-283-000
PIN, SHIFT FORK, åtgår 3st
50:-
28
24261-374-000
SHAFT,SHIFT FORK
*
29
24263-286-000
CLIP, SHIFT FORK
84:-
30
24300-374-000
DRUM,GEAR SHIFT
*
31
24301-374-000
DRUM, GEARSHIFT
*
32
24302-374-000
CENTER,GEAR SHIFT
*
33
24305-374-000
PLATE,BEARING SET
*
34
24421-230-000
PIN,SHIFT DRUM, åtgår 5st
95:-
35
24430-374-000
STOPPER, SHIFT DRUM
*
36
24433-323-010
COLLAR,SHIFT DRUM
*
37
24434-286-020
PLATE,STOPPER CAM
*
38
24435-323-020
SPRING,SHIFT DRUM
113:-
39
24440-374-000
STOPPER
*
40
24610-374-000
SPINDLE,GEARSHIFT
*
41
24641-292-000
SPRING,SHIFT ARM
71:-
42
24651-286-000
SPRING,RETURN
80:-
43
25100-374-003
BEARING,OIL PUMP
*
44
28101-323-000
GEAR,STARTER
1893:-
45
28106-323-000
SHAFT,STARTER
*
46
28111-363-000
GEAR,STARTING
*
47
28112-323-000
SPACER,25MM
88:-
48
28120-323-000
OUTER,START CLUH
*
49
28125-323-000
SPRING,START CLUH, åtgår 3st
40:-
50
28126-323-000
CAP,START ROLLER, åtgår 3st
85:-
51
28211-323-000
PINION,KICK START
533:-
52
28215-216-000
SPRING, STARTER
72:-
53
28221-310-010
(28221-310-020) RATCHET,KICK
*
53
28221-310-020
RATCHAT,STARTER
*
54
28223-216-000
SPRING, STARTER
93:-
55
28251-323-000
SPINDLE,STARTER
*
56
28258-310-010
PLATE,GUIDE
133:-
57
28261-323-000
SPRING,STARTER
*
58
90015-286000
PIN,RETURN SPRING
*
59
90433-283000
WASHER, LOCK, 6MM
*
60
90451-216000
WASHER, THRUST
*
61
90451-286000
WASHER THRUST 25, åtgår 3st
99:-
63
90454-200000
WASHER, THRUST
30:-
63
90457-HB3000
WASHER,THRUST,16X
45:-
64
90456-323000
WASHER (22MM)
*
66
90458-292000
WASHER,THRUST
95:-
67
90461-286000
WASHER THRUST 25
60:-
68
90462-323000
WASHER,LOCK 25MM
45:-
69
90555-700000
WASHER,THRUST
*
70
90602-259010
SET-RING, 25M/M, åtgår 5st
50:-
71
91001-MN8911
BEARING,RADIAL BA
370:-
71
91001-116008
B/BRG RAD N/COM
320:-
71
91001-436003
B/BRG RAD N/COM
320:-
71
91002-KY4901
BRG,BALL,RADIAL 6
370:-
72
91002-283000
B/BRG N/RAD N/COM
*
72
91002-283003
(91002-283-000) B/BRG RAD N/COM
*
73
91002-286008
B/BRG N/RAD N/COM
531:-
74
91007-323000
NEEDLE BRG
*
75
91008-374003
B/BRG RAD N/COM
290:-
76
91022-374003
NEEDLE BRG
321:-
77
91101-377000
ROLLER,10.2X11.5, åtgår 3st
40:-
77
91103-259000
ROLLER 10.2X11.5, åtgår 3st
40:-
78
91103-374003
PIN,OIL PUMPKNOCK
*
79
91201-283005
OIL SEAL,12X25X45
55:-
79
91201-292003
OIL SEAL 12X25X45
55:-
79
91202-426003
OILSEAL,12X25X4.5
55:-
80
91202-KFL841
OIL SEAL 13.8X24X
65:-
80
91202-216000
OIL SEAL
65:-
80
91202-302000
OIL SEAL 14X24X5
65:-
80
91202-302010
OIL SEAL,13.8X24X
65:-
80
91205-HB2771
OIL SEAL,13.8X24X
75:-
80
91205-HB2772
OIL SEAL 13.8X24X
75:-
80
91205-035303
OIL-SEAL,138245
65:-
81
91205-283010
OIL SEAL 33X57X7
130:-
81
91205-283015
OIL SEAL,33X57X7
130:-
82
91207-374000
OIL SEAL,34X9
32:-
83
91306-703000
O RING,24.5MM
*
84
92000-06012
BOLT,HEX 6X12, åtgår 3st
20:-
84
92101-06012
BOLT,HEX.,6X12, åtgår 3st
20:-
84
92101-060120A
BOLT,HEX.,6X12, åtgår 3st
20:-
85
92000-06014
BOLT,HEX 6X14, åtgår 2st
20:-
85
92101-060140A
BOLT,HEX.,6X14, åtgår 2st
20:-
86
92000-06016
BOLT,HEX., 6X16, åtgår 2st
10:-
86
92000-060160A
BOLT,HEX 6X16, åtgår 2st
10:-
86
92000-060161A
BOLT,HEX.,6X16, åtgår 2st
10:-
86
92100-060160A
BOLT,HEX.,6X16, åtgår 2st
5:-
86
92101-060160A
BOLT,HEX.,6X16, åtgår 2st
10:-
86
92200-060160A
BOLT,HEX,6X16, åtgår 2st
10:-
87
92020-06020
BOLT,HEX 6X20
20:-
88
92200-06032
BOLT, HEX. (6X32)
*
88
92201-060320A
BOLT, HEX. (6X32)
*
89
93600-06018
SCREW CROSS 6X18, åtgår 3st
15:-
90
94303-08140
PIN,KNOCK 8X14
20:-
91
94510-12000
CIRCLIP,EX,12
10:-
92
94510-18000
CIRCLIP, 18M/M
30:-
93
94510-20000
CIR CLIP,EX.20
15:-
94
94510-30000
CIRCLIP, 30M/M
40:-
95
96100-62050
(96100-620-5000) B/BRG RAD N/COM
215:-
95
96100-6205000
B/BRG RAD N/COM
215:-
95
96100-6205010
B/BRG RAD N/COM
*
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
