1
24701-393-771
PEDAL,GEAR CHANGE
*
2
24781-371-000
RUBBER,CHANGE
65:-
3
35350-086-721
(35350-GB2-505) SWITCH ASSY.,STOP
305:-
4
35357-393-000
SPRING,STOP SW.
*
5
35360-393-771
SWITCH,PARKING
*
5
35360-393-772
SW ASSY,PARKING
*
6
43451-393-770
ROD, RR. BRAKE
*
7
46500-393-771
PEDAL, BRAKE
*
8
46501-393-770
JOINT, RR. BRAKE
*
9
46510-393-772
SPINDLE, RR. BRAKE
*
10
46514-393-771
SPRING, BRAKE PEDAL
*
11
46601-393-770
BASE, RATCHET
*
12
46602-393-770
LEVER, RATCHET
*
13
46604-393-003
CASE, RATCHET
*
14
46605-393-013
POLE, RATCHET, åtgår 4st
*
15
46606-393-010
SPRING
*
16
46607-393-010
SPRING, POLE SET
*
17
46608-393-003
WASHER (38X29.5X1)
*
18
46620-393-772
CABLE,P/BRK
*
19
46625-393-000
BRACKET
*
20
46625-393-770
GASKET
*
21
46626-393-770
COVER, RATCHET
*
22
46628-393-771
O-RING (18.8X1.5)
*
23
46629-393-771
SEAL,26.5X33X4
*
24
50600-393-771
HOLDER, R. MUFFLER
*
25
50604-393-772
HOOK,DRAIN TUBE
*
26
50610-393-770
HOLDER, L. MUFFLER
*
27
92000-06020
BOLT,HEX 6X20
20:-
27
92101-060200A
BOLT,HEX.,6X20
20:-
28
92140-06040
BOLT,HEX,6X40
*
29
93482-0802800
BOLT-WASHER 8X28
*
30
93500-06020
SCREW,CROSS 6X20
10:-
30
93500-060200A
SCREW,CROSS 6X20
10:-
31
93500-060280B
SCREW,PAN,6X28, åtgår 2st
35:-
31
93500-0602802
SCREW,CROSS,6X28, åtgår 2st
35:-
32
93892-0601200
SCREW-WASHER,6X12
*
33
93892-0601600
SCREW-WASHER,6X16, åtgår 2st
10:-
34
90310-KA3711
NUT HEX 6MM
15:-
34
94000-060000S
NUT,HEX.,6MM
1251:-
34
94001-060000S
NUT,HEX 6MM
15:-
34
94001-060080S
NUT,HEX.,6MM
1251:-
34
94001-062000S
NUT,HEX.,6MM
15:-
34
94030-06000
NUT,HEX 6MM
15:-
35
94002-06000
NUT,THIN 6MM
15:-
35
94002-060000S
NUT,THIN 6MM
1306:-
36
94201-16150
PIN,COTTER 1.6X15
5:-
36
94201-16250
PIN SPLIT,1.6
10:-
37
94301-08120
PIN,KNOCK 8X12A
25:-
38
94511-29000
CIRCLIP (29MM)
*
39
95014-73100
SPG.A,BRAKE ROD
20:-
40
95015-32001
JOINT, BRAKE ARM
20:-
41
95015-42000
NUT,ADJUST
50:-
42
95015-52000
PIN,JOINT
50:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
