1
13491-300-000
RING,SET.66.5MM
*
2
13496-300-000
RING B,SET
15:-
3
13620-300-010
TENSIONER PRIMARY
2545:-
4
23110-392-000
SPROCKET,DRIVEN
*
5
23131-300-015
CHAIN,PRIMARY, åtgår 2st
1860:-
7
23511-300-020
GEAR,FINAL DRIVEN
*
9
23521-392-000
SHAFT,DRIVEN
667:-
14
23801-300-620
SPROCKET,DRIVE
*
15
23811-292-000
PLATE,FIXING
35:-
16
28210-300-000
GEAR,KICK STARTER
*
17
28250-300-020
SPINDLE,KICK
*
18
28251-300-030
(28271-393-000) FRANGE KICK
*
18
28271-393-000
FLANGE,KICK STAT
591:-
19
28252-300-020
PAWL,KICK STARTER
125:-
20
28253-300-000
SPRING,STARTER
*
21
28254-300-000
PIN,KICK STOPPER
*
22
28255-300-000
PIN,4X37
79:-
23
28256-300-000
PIN,6X35
*
24
28261-300-010
SPRING,RETURN
*
26
91004-300000
B/BRG RAD N/COM
*
27
91006-300008
(91021-KV3-771) BEARING (6205)
290:-
28
91008-300008
(91012-MG7-003) B/BRG N/RAD N/COM
710:-
29
91010-300008
BEARING (25X32X20), åtgår 2st
*
30
91205-300005
OIL SEAL,
200:-
32
92000-06012
BOLT,HEX 6X12, åtgår 2st
20:-
33
92000-06016
BOLT,HEX., 6X16
10:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
