1
11311-MER-D00
COVER, PULSER
3061:-
2
11330-MER-D00
COVER COMP., CLUTCH
3945:-
3
11332-MER-D00
CAP, 45MM
245:-
4
11391-MV9-670
GASKET, PULSER COVER
175:-
5
11393-MV9-670
GASKET, CLUTCH COVER
335:-
6
15650-MBZ-610
GAUGE, OIL LEVEL
230:-
7
22810-MBZ-610
LEVER COMP., CLUTCH
860:-
8
22815-MBZ-D00
SPRING, CLUTCH LEVER
70:-
9
22821-MBZ-610
RECEIVER, CLUTCH CABLE
140:-
10
30291-MV9-671
ROTOR, PULSE
280:-
11
30300-MBZ-611
GENERATOR ASSY., PULSE
1320:-
12
90006-GHB680
BOLT, FLANGE, 6X28 (NSHF), åtgår 18st
60:-
13
90013-430000
BOLT, SPECIAL, 10X25
245:-
14
90405-MCA780
WASHER, 10.5X27
115:-
15
90525-MBZ610
WASHER
40:-
16
90650-KV6003
BAND, WIRE, 95MM
55:-
17
91204-KK0003
OIL SEAL, 12X18X5 (ARAI)
90:-
18
91301-ML7003
O-RING, 48.1X3.6 (ARAI)
80:-
19
91302-KE8003
O-RING, 18X3 (ARAI)
55:-
20
94301-08140
DOWEL PIN, 8X14, åtgår 4st
25:-
21
95701-0601400
BOLT, FLANGE, 6X14, åtgår 2st
15:-
