1
19010-MER-D12
RADIATOR COMP.
7867:-
2
19014-KEA-003
NUT, SETTING, åtgår 3st
50:-
3
19015-MER-D01
SHROUD COMP.
1195:-
4
19020-MCF-013
FAN COMP., COOLING
915:-
5
19030-MER-D01
MOTOR ASSY., FAN
7690:-
6
19032-MCZ-010
GRILLE, RADIATOR
1055:-
7
19039-MER-D10
NECK, FILLER
200:-
8
19045-MY3-621
CAP COMP., RADIATOR
660:-
9
19051-KA3-830
RUBBER, RADIATOR MOUNTING, åtgår 3st
85:-
10
19052-MN8-000
COLLAR, RADIATOR MOUNTING, åtgår 2st
70:-
11
19055-MV9-881
SEAL, RADIATOR CAP (ENGLISH/FRENCH/JAPANESE)
120:-
12
19101-MER-D00
TANK, RADIATOR RESERVE
745:-
13
19104-MB0-700
CAP, RESERVE TANK
140:-
14
19105-MER-D00
TUBE, 5.3X1130
235:-
15
19120-MBZ-G00
PROTECTOR, RADIATOR UPPER HOSE
340:-
16
19501-MER-D10
HOSE, RADIATOR UPPER (A)
85:-
17
19502-MER-D10
HOSE, RADIATOR UPPER (B)
140:-
18
19503-MER-D00
HOSE, RADIATOR LOWER
135:-
19
19516-GAG-003
CLAMP, HOSE, 30-37MM, åtgår 4st
145:-
20
19516-MER-D10
CLAMP, HOSE, 30-37MM, åtgår 2st
230:-
21
37760-MT2-003
SWITCH ASSY., THERMO
1333:-
22
90111-162000
BOLT, FLANGE, 6MM
60:-
23
90111-187000
BOLT, FLANGE, 6MM
80:-
24
90315-MK3003
NUT, SERRATE, 5MM, åtgår 4st
45:-
25
91307-PH7660
O-RING, 13.5X1.4
30:-
26
93401-0601408
BOLT-WASHER, 6X14, åtgår 3st
40:-
27
93901-22180
SCREW, TAPPING, 3X8
5:-
28
94050-06070
NUT, FLANGE, 6MM
20:-
29
95002-02100
CLIP, TUBE (B10), åtgår 3st
15:-
30
95005-5560020S
TUBE, 5.3X550 (95005-55001-20M)
*
31
96001-0602500
BOLT, FLANGE, 6X25
25:-
32
96001-0602807
BOLT, FLANGE, 6X28
25:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
