1
11105-KE1-000
EMBLEM, CYLINDER HEAD COVER
*
2
12110-KE1-010
CYLINDER COMP.
*
3
12191-KE1-306
GASKET, CYLINDER
*
4
12210-KE1-305
HEAD, CYLINDER
*
5
12251-KK4-306
GASKET, CYLINDER HEAD
140:-
6
12301-KE1-010
COVER, CYLINDER HEAD
*
6
12210-KE1-305
COVER, CYLINDER HEAD
*
9
12303-KE1-000
COVER, HERP
*
12
12305-KE1-003
PLATE, THERMOSTAT FIXING
*
13
12307-KE1-000
COLLAR, HEAD COVER, åtgår 2st
35:-
14
12391-KE1-000
PACKING, HEAD COVER
*
15
14100-KE1-000
VALVE COMP., REED
*
16
14131-KE1-306
GASKET A, REED VALVE
45:-
18
14132-KE1-306
GASKET B, REED VALVE
50:-
20
17256-GF5-000
BAND, AIR CLEANER CONNECTING TUBE
*
21
19300-KE1-003
THERMOSTAT ASSY.
850:-
22
19510-KE1-000
HOSE A, WATER
*
23
19514-ME9-003
CLAMP, WATER HOSE, åtgår 2st
85:-
24
37750-PC1-004
THERMO UNIT (DENSO)
965:-
25
90417-001000
WASHER, GEARSHIFT DRUM SIDE
*
26
90461-357000
WASHER, SEALING, 12MM
80:-
27
91302-KE1003
O-RING, 20X2.9
*
27
91302-KE1003
O-RING, 20.3X3.0
*
27
91305-384750
O-RING, 25X3
65:-
29
92900-060280B
BOLT, STUD, 6X28, åtgår 2st
30:-
30
92900-080190B
BOLT, STUD, 8X19, åtgår 2st
40:-
31
92900-080280B
BOLT, STUD, 8X28, åtgår 5st
55:-
32
93500-040120G
SCREW, PAN, 4X12
1251:-
33
93500-040250A
SCREW, PAN, 4X25
1306:-
35
93902-34180
SCREW, TAPPING, 4X8, åtgår 2st
10:-
36
94050-06000
NUT, FLANGE, 6MM, åtgår 2st
15:-
37
94050-08000
NUT, FLANGE, 8MM, åtgår 9st
20:-
38
96001-0601200
BOLT, FLANGE, 6X12, åtgår 3st
30:-
39
96001-0602800
BOLT, FLANGE, 6X28, åtgår 4st
35:-
40
98079-57816
PLUG, SPARK (BR7ES NGK)
75:-
40
98079-57857
PLUG, SPARK (W22ESR-U DENSO)
75:-
40
98079-58846
PLUG, SPARK (BR8ES)(NGK)
75:-
40
98079-59827
PLUG, SPARK (W24ESR-U DENSO)
75:-
40
98079-59816
PLUG, SPARK (BR9ES NGK)
75:-
40
98079-59827
PLUG, SPARK (W27ESR-U DENSO)
75:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
