1
11210-MCS-010
PAN, OIL
3787:-
2
11211-MCS-010
CLAMP A, DRAIN HOSE
110:-
3
11219-MCS-D80
CLAMP, TUBE
90:-
4
15100-MCS-010
PUMP ASSY., OIL
5293:-
5
15134-MCS-000
SPROCKET, OIL PUMP DRIVEN (30T)
560:-
6
15150-MCS-000
STRAINER COMP., OIL
765:-
7
15154-MM5-000
PACKING, OIL STRAINER
105:-
8
15160-MCS-000
PIPE COMP., OIL SCAVENGING
925:-
9
15220-MW0-000
VALVE ASSY., RELIEF
505:-
10
15311-MCS-000
PIPE A, OIL PATH
255:-
11
15312-MCS-000
PIPE B, OIL PATH
225:-
13
15433-KGB-610
SEAL, RING
60:-
14
15700-MCS-003
COOLER COMP., OIL
7071:-
15
19225-MCS-003
CHAIN, WATER PUMP DRIVE (70L)
505:-
16
23929-PX4-700
WASHER, SPRING, 24MM
*
17
90004-GHB680
BOLT, FLANGE, 6X28 (NSHF), åtgår 14st
40:-
18
90004-MCS000
BOLT, DRAIN PLUG, 14MM
90:-
19
90019-MCJ000
BOLT, OIL COOLER
945:-
20
90021-MM5000
BOLT-WASHER, 6X12
80:-
21
90501-MB0000
DOWEL PIN, 8X14, åtgår 2st
35:-
22
91313-MG7004
O-RING, 14.7X2.2 (ARAI)
85:-
23
91315-MCS003
SEAL, OIL PATH PIPE, 20.3MM, åtgår 4st
80:-
24
94109-14000
WASHER, DRAIN PLUG, 14MM
10:-
25
95701-0601000
BOLT, FLANGE, 6X10
25:-
26
95701-0601400
BOLT, FLANGE, 6X14
15:-
27
95701-0608000
BOLT, FLANGE, 6X80, åtgår 3st
40:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
