1
24702-MEG-000
ARM COMP., CHANGE
1080:-
2
24710-MEG-000
PEDAL COMP., GEAR CHANGE
1525:-
3
24724-MBW-D21
COVER, DUST, åtgår 2st
150:-
4
24781-371-000
RUBBER, CHANGE PEDAL
65:-
5
35350-MEG-010
SWITCH ASSY., RR. STOP
470:-
6
35357-KR3-670
SPRING, STOP SWITCH
75:-
7
43451-MEG-000
ROD COMP., RR. BRAKE
210:-
8
45423-KA4-700
NUT, HEX., 6MM (LEFT HAND THREAD)
50:-
9
46500-MEG-640
PEDAL ASSY., RR. BRAKE
1555:-
10
46511-MEG-000
ARM, RR. BRAKE MIDDLE
870:-
11
46514-KZ9-000
SPRING, BRAKE PEDAL
65:-
12
46515-MM8-000
COLLAR, RR. BRAKE PIVOT
105:-
13
46517-MEG-000
SHAFT, RR. BRAKE PIVOT
320:-
14
46540-MEG-000
ROD, RR. BRAKE MIDDLE
855:-
15
46545-MBA-000
PIN, MIDDLE ROD JOINT, åtgår 2st
70:-
16
53312-657-000
WASHER, BUSH
65:-
17
90065-MEG000
BOLT, TIE ROD
215:-
18
90133-MAT000
BOLT, FLANGE SOCKET, 8X32
135:-
19
90521-427770
WASHER, 10.3MM
40:-
20
91206-968003
DUST SEAL, 17X23X3 (NOK), åtgår 6st
85:-
21
92101-060200A
BOLT, HEX., 6X20
20:-
22
94002-060000S
NUT, HEX., 6MM, åtgår 2st
15:-
23
94201-20120
PIN, SPLIT, 2.0X12
10:-
24
94201-20150
PIN, SPLIT, 2.0X15, åtgår 2st
10:-
25
94511-15000
CIRCLIP, EXTERNAL, 15MM
10:-
26
95014-73100
SPRING A, BRAKE ROD
20:-
27
95015-32001
JOINT B, BRAKE ARM
20:-
28
95015-42000
NUT B, BRAKE ROD ADJUSTING
50:-
29
95015-53000
PIN C, JOINT
30:-
30
95701-0602000
BOLT, FLANGE, 6X20
25:-
31
95801-1005000
BOLT, FLANGE, 10X50
40:-
