1
15510-MBN-670
HOSE A, OIL
1673:-
2
15517-KCY-670
BOLT A, OIL HOSE
200:-
3
15520-MBN-670
HOSE B, OIL
1570:-
4
15630-MG3-010
PLATE
180:-
5
15650-MBN-670
GAUGE, OIL LEVEL
300:-
6
15710-MBN-670
PIPE COMP., OIL
890:-
7
CLAMPER, OIL PIPE
*
8
COVER, DRIVE CHAIN
*
9
STAY, CHAIN COVER
*
10
50100-MBN-650ZA
BODY COMP., FRAME *NH146M*
*
11
50185-MN1-670
TUBE, BREATHER (7.3X335)
255:-
12
50219-MBN-670
STAY, MUFFLER
595:-
13
PLATE, RR. ENGINE HANGER
*
14
50225-MBN-670
NUT, PLATE ENGINE HANGER
95:-
15
50232-MBN-670
PLATE, PROTECTOR
80:-
16
50255-MBN-670
GUIDE, CABLE
95:-
17
50300-MBN-650
BODY ASSY., RR. FRAME
5092:-
18
50351-MBN-670ZC
PLATE, SKID *NH146M*
1030:-
19
PLATE, R. ENGINE HANGER UPPER
*
20
50532-MBN-670
PLATE, L. ENGINE HANGER UPPER
610:-
21
PLATE, FR. ENGINE HANGER OUTER
*
22
PLATE, LOWER ENGINE HANGER
*
23
PLATE, R. ENGINE HANGER
*
24
50912-MBN-670
SLIDER, CHAIN GUIDE
470:-
26
53603-051-000
RIVET, 4.1MM
30:-
28
77227-MBG-300
TAPE B, SINGLE SEAT COWL
40:-
29
90102-MBN670
BOLT, SOCKET, 8X38
85:-
30
90106-KCZ000
SCREW, SPECIAL, 6MM, åtgår 4st
65:-
32
90152-MBN671
BOLT, FLANGE, 10X109
120:-
33
90154-MBN670
BOLT, FLANGE, 10X115
145:-
34
90156-MBN670
BOLT, FLANGE, 10X120
60:-
35
90157-MBN670
BOLT, FLANGE, 8X73.5, åtgår 2st
70:-
36
90158-MBN670
BOLT, FLANGE, 8X106, åtgår 2st
55:-
37
90159-MBN670
BOLT, FLANGE, 8X69, åtgår 2st
70:-
38
90161-MBN670
BOLT, FLANGE, 8X115
115:-
39
90301-KBW940
NUT, CAP, 8MM, åtgår 2st
55:-
40
90311-MN1670
CLAMP, TUBE (D12.5), åtgår 2st
45:-
41
90410-SD3660
WASHER, PLAIN, 8MM, åtgår 4st
*
42
90442-028000
WASHER, SEALING, 8MM
30:-
43
90450-KG8000
COLLAR, 8MM
65:-
44
90451-KAF000
WASHER, 8MM, åtgår 2st
30:-
45
90501-MT2000
WASHER
40:-
46
90529-126770
WASHER, 10.5MM, åtgår 3st
45:-
48
91302-KE8003
O-RING, 18X3 (ARAI)
55:-
49
91302-MG2792
GASKET, RUBBER, 10.5MM, åtgår 2st
75:-
50
91305-PE2003
O-RING, 9.8X1.9
30:-
51
91509-HC0000
BOLT, FENDER SETTING, 5X11.5, åtgår 2st
90:-
52
94050-05070
NUT, FLANGE, 5MM, åtgår 2st
15:-
53
94050-08000
NUT, FLANGE, 8MM, åtgår 4st
20:-
54
94050-10000
NUT, FLANGE, 10MM, åtgår 4st
25:-
55
94109-12000
WASHER, DRAIN PLUG, 12MM
16:-
56
94109-14000
WASHER, DRAIN PLUG, 14MM
15:-
57
94301-10160
DOWEL PIN, 10X16
30:-
58
96001-0601200
BOLT, FLANGE, 6X12
30:-
59
96001-0601600
BOLT, FLANGE, 6X16
20:-
60
96001-0601607
BOLT, FLANGE, 6X16, åtgår 2st
30:-
61
96300-0801800
BOLT, FLANGE, 8X18
25:-
62
96300-0803500
BOLT, FLANGE, 8X35
30:-
63
96300-0804000
BOLT, FLANGE, 8X40, åtgår 2st
30:-
64
96700-0802810
BOLT, SOCKET, 8X28
35:-
65
90101-KZ1600
BOLT, FLANGE, 10X75
100:-
66
15500-KCZ-000
STRAINER COMP., OIL
660:-
67
91305-384750
O-RING, 25X3
65:-
68
91406-166000
CLIP, WIRE
50:-
69
96300-0601200
BOLT, FLANGE, 6X12
30:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
