5
57331027044
% CARBURETOR COVER 2002
368:-
10
57331080000
BRACKET PLATE FOR THR. CABLE
418:-
11
57331055000
SCREW M 5 X 8, åtgår 2st
36:-
12
57331046000
THROTTLE SHAFT CPL.
817:-
14
57331046050
COIL SPRING THROTTLE SHAFT
113:-
16
57331035051
LINK ARM THROTTLE VALVE CPL.
817:-
18
59031029006
SLIDE STOP L=44MM 04 450-650 FE+FS (EU+AUS)
96:-
19
57331035000
THROTTLE VALVE CPL.
1612:-
20
59031035050
BUSHING THROTTLE VALVE, åtgår 4st
96:-
21
57331035153
% GASKET PLATE THROTTLE VALVE
817:-
22
59031035052
GASKET WASHER THROTTLE VALVE
89:-
23
57331034300
JET NEEDLE KEIHIN OBEKR
215:-
23
59031023200
JET NEEDLE KEIHIN OBDVT 450-650 FE+FS
171:-
23
59031022000
% JET NEEDLE KEIHIN OBDVR 450/550 FC
164:-
24
59031029000
BAR CLIP
28:-
25
57331032000
NEEDLE SET SCREW CPL.
253:-
26
59031121000
NEEDLE JET FCR-MX
171:-
27
54531623160
MAIN JET 160 KEIHIN 650 FE+FS
119:-
27
54531623162
MAIN JET 162 KEIHIN
119:-
27
54531623165
MAIN JET 165 KEIHIN
119:-
27
54531623168
MAIN JET 168 KEIHIN
119:-
27
54531623170
MAIN JET 170 KEIHIN
111:-
27
54531623172
MAIN JET 172 KEIHIN
119:-
27
54531623175
MAIN JET 175 KEIHIN
119:-
27
54531623178
MAIN JET 178 KEIHIN 450/501 FE+FS
119:-
27
54531623180
MAIN JET 180 KEIHIN
119:-
27
54531623182
MAIN JET 182 KEIHIN 450/550 FC, 550 FE
119:-
27
54531623185
MAIN JET 185 KEIHIN
111:-
27
54531623188
MAIN JET 188 KEIHIN
119:-
27
54531623190
MAIN JET 190 KEIHIN
111:-
28
54531607038
IDLE JET 38 KEIHIN 450-650 FE+FS
119:-
28
54531607040
IDLE JET 40 KEIHIN 450/550 FC
111:-
28
54531607042
IDLE JET 42 KEIHIN
111:-
28
54531607045
IDLE JET 45 KEIHIN
111:-
29
59031051085
STARTER JET 85
119:-
30
57331007100
IDLE AIR JET 100 KEIHIN
140:-
31
57331037200
MAIN AIR JET 200 KEIHIN
*
32
59031017100
ADJUST SCREW CPL. FCR-MX
174:-
35
57331085000
BUFFER PLATE
126:-
39
57331009000
FLOAT CPL.
588:-
40
57331008000
ARM PIN FLOAT
64:-
41
57331075100
% HOT-STARTER VALVE CPL.
719:-
42
57331020000
NEEDLE VALVE CPL.
377:-
47
57331060000
COVER ACCELERATOR PUMP
279:-
49
78031011000
% FLOAT CHAMBER CPL. SET 04
1444:-
52
57331090000
AIR CUT VALVE 2002 ONLY FOR 650 FE+FS
687:-
53
59031059000
COIL SPRING
89:-
55
57331048000
STARTER VALVE CPL.
588:-
60
0965050103
FLAT HEAD SCREW DIN0965-M 5X10
15:-
61
57331014000
HOLDING BOLT
220:-
64
57331062000
INTERMEDIATE LEVER CPL.
245:-
65
57331056000
LINK LEVER
126:-
66
57331059000
SPRING LINK LEVER
113:-
67
57331159000
SPRING INTERMEDIATE LEVER
113:-
68
57331038000
CARBURETOR COVER
177:-
69
57331087000
WASHER LINK LEVER
36:-
70
57331084000
E-CLIP
36:-
72
57331061000
ROD ACCELERATOR PUMP
245:-
87
59031040010
O-RING FOR INTAKE FUNNEL
63:-
89
0912050123
AH SCREW DIN0912-M 5X12, åtgår 2st
15:-
96
57331077100
% THROTTLE POSITION SENSOR
2168:-
99
57331099000
GASKET SET FCR-MX KEIHIN
828:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
