3
13251-09211
GASKET, FLOAT CHAMBER
113:-
4
13252-09210
FLOAT
409:-
5
13254-01010
PIN
32:-
6
13268-05010
THROTTLE ADJUSTER SPRING (0000)
93:-
7
13269-01010
PILOT AIR ADJUSTING SCREW
242:-
8
13268-01010
SPRING (M12MARK2,M15D,M12M12MARK2,M15D,M12)
48:-
9
13370-09211
NEEDLE VALVE ASS'Y
1003:-
10
13382-03110
WASHER
24:-
11
13383-12011
NEEDLE, JET
307:-
12
13392-01010
NEEDLE VALVE SEAT GASKET
22:-
14
13411-01010
VALVE, STARTER
277:-
15
13417-01010
SPRING
60:-
17
13551-12110
VALVE, THROTTLE
*
18
13573-36110
SPRING, THROTTLE VALVE RETUR (O K10-431800 OD=18(0.71)I.D=16.4=7
48:-
19
13581-09210
PLATE
53:-
20
13296-11010
ROD, THROTTLE STOP
112:-
21
13688-08010
THROTTLE ADJUSTER CAP
72:-
22
13267-05010
THROTTLE VALVE STOP SCREW
228:-
25
13661-03010
NUT, åtgår 2st
65:-
26
13247-05010
PLUG, DRAIN
67:-
27
13249-05010
GASKET, DRAIN PLUG
23:-
28
09491-75001
MAIN JET
*
29
09492-35001
** SUPERSEEDED
*
30
09494-00029
JET, NEEDLE
*
31
09491-65001
JET, MAIN
*
31
09491-70001
JET, MAIN
*
31
09491-80001
MAIN JET
*
31
09491-85001
JET, MAIN
*
31
09491-90001
JET MAIN 90
*
32
09492-40002
JET, PILOT
*
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
