1
12110-12000
PISTON (STD)
*
1
12110-12000-050
PISTON (OS:0.5)
*
1
12110-12000-100
PISTON (OS:1.0)
*
2
12140-12012
PISTON RING SET
*
2
12140-12012-050
RING SET, PISTON (OS:0.5)
*
2
12140-12012-100
RING SET, PISTON (OS:1.0)
*
4
09381-14001
CIRCLIP, åtgår 2st
24:-
6
12200-12002
CRANKSHAFT ASSY
*
8
09160-19001
THRUST WASHER, åtgår 2st
62:-
9
12211-03300
PIN, CRANK
513:-
11
12220-12000
CRANKSHAFT, RH
*
12
12261-12002
CRANKSHAFT, LH
*
14
12353-12001
SPACER
*
18
09262-20015
BEARING, RH (00 ID=20(0.79) OD=52(2.0.59))
718:-
20
12410-12010
PLATE, VALVE
737:-
21
12421-05210
GUIDE, VALVE
369:-
23
12450-12000
SEAT, OUTER VALVE
*
24
09280-22002
VALVE SEAT OUTER "O" RING
33:-
25
09280-10002
O RING
*
26
09280-99001
O RING, OUTER VALVE SEAT
69:-
27
12461-12001
SEAT, INNER VALVE
918:-
28
12471-12000
GASKET, INNER VALVE SEAT
55:-
31
12511-03100
PLATE, OIL GUIDE
133:-
32
21111-07001
GEAR, PRIMARY DRIVE
*
33
09180-20006
SPACER
108:-
34
09140-14002
PRIMARY DRIVE GEAR NUT (M12MARK2,M15D,M12 UP TO106050)
53:-
35
09166-14004
WASHER
550:-
37
08341-31039
KEY
30:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
