1
24131-36C01
SHAFT, DRIVE (NT:11)
*
2
21210-04C00
FACE, FIXED DRIVEN
1595:-
3
09201-06005
PIN, åtgår 3st
42:-
4
09262-12018
BEARING (12X24X6)
280:-
6
09263-17042
BEARING, FIXED DRIVEN, R
453:-
7
21240-09E01
FACE, MOVABLE DRIVEN
*
8
09283-34007
OIL SEAL (34X41X4), åtgår 2st
133:-
9
09280-41005
O RING (D:4.6,ID:41.9), åtgår 2st
40:-
11
09440-52007
SPRING
610:-
12
21220-04C11
HOUSING, CLUTCH
*
13
21501-29C10
CLUTCH ASSY, SHOE
2419:-
14
09140-28004
NUT
105:-
16
24150-29C24
SHAFT, IDLE
*
17
08113-62017
BEARING, RH
278:-
18
08331-31156
CIRCLIP
25:-
19
08211-12201
WASHER
*
20
08211-16251
THRUST WASHER
*
21
08113-62017
BEARING, RH
278:-
22
08113-63030
BEARING, R
320:-
23
09283-17018
OIL SEAL (17X27X5)
142:-
24
24141-36C01
SHAFT, REAR AXLE
1945:-
25
24371-29C00
GEAR, FINAL DRIVEN (NT:41)
1865:-
27
09283-27010
OIL SEAL, LH
153:-
28
08130-62047
BEARING
448:-
29
24751-09E00
RETAINER, BEARING
*
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
