3
13279-45410
SCREW, PILOT
*
4
13268-47070
SPRING
38:-
5
13604-44080
SCREW, åtgår 2st
55:-
6
13551-33200
THROTTLE VALVE (125)
*
7
09491-33004
JET, PILOT AIR (165)
175:-
8
13503-01400
SPRING
*
9
13502-33210
COVER
418:-
10
13394-10010
CLIP, NEEDLE
63:-
11
13389-37400
PLATE
92:-
13
13557-47070
WASHER
72:-
14
13574-01400
RING
*
15
13411-01400
PLUNGER ASSY
187:-
16
13278-02330
O RING
24:-
17
13417-01010
SPRING
60:-
18
13418-43200
CAP
177:-
21
13357-44080
PLUG
85:-
22
13383-01400
NEEDLE, JET
*
22
13383-01420
NEEDLE, JET
*
23
09494-00396
JET, NEEDLE (O-8)
*
23
09494-00417
JET, NEEDLE (P-0)
*
25
13382-03110
WASHER
24:-
26
13373-11400
PLATE
125:-
28
13250-05300
FLOAT
542:-
29
13254-92311
PIN, FLOAT
30:-
30
13370-01401
VALVE ASSY, NEEDLE
1125:-
35
13553-01400
LEVER
*
37
13606-47070
WASHER
45:-
38
13573-37100
SPRING
*
40
13267-01400
ADJUSTER
*
41
13627-01400
BRACKET
*
42
13427-38300
WASHER
22:-
43
13271-93011
SPRING
*
44
13247-02340
SCREW, DRAIN
48:-
47
13550-01400
SHAFT ASSY, THROTTLE
*
48
13627-01410
BRACKET
*
49
13604-01400
SCREW
*
51
13388-44030
SPRING
103:-
52
13382-44030
WASHER
54:-
53
13387-47010
RING
67:-
56
13684-18900
HOSE, OVER FLOW (3X5X500)
*
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
