2
13551-45B00
VALVE,THROTTLE (115)
*
3
13382-42A00
RING
60:-
5
13417-44B00
SPRING
133:-
6
13502-45B00
COVER, DIAPHRAGM
*
7
13551-44B10
VALVE, PISTON
1357:-
9
13387-44480
RING
*
10
13550-14E00
SHAFT ASSY
*
11
13268-31D00
SPRING
200:-
12
13557-47070
WASHER
72:-
13
13617-44080
E RING
35:-
14
13556-44B00
SEAL, åtgår 2st
72:-
15
13247-13A00
SCREW, DRAIN
67:-
17
13258-44B00
GASKET, FLOAT CHAMBER
137:-
18
13240-17E10
FLOAT ASSY
1033:-
21
09491-26011
JET, MAIN (130)
193:-
22
13383-14D10
NEEDLE, JET (5CD56-3)
255:-
25
13267-14D10
ADJUSTER
398:-
26
13271-33C00
SPRING
78:-
27
13427-38300
WASHER
22:-
28
13411-14E00
PLUNGER ASSY
*
29
13574-28A00
RING
*
31
09492-35010
JET, PILOT (37.5)
175:-
32
13671-48B10
CLIP
*
33
13279-47070
SCREW, PILOT (1,1/2)
187:-
34
13268-47070
SPRING
38:-
35
13291-29900
WASHER
17:-
37
13247-32210
CAP, DRAIN
165:-
38
13249-41310
O RING
92:-
39
09493-24007
JET, AIR (1.2)
260:-
40
09493-60004
JET, MAIN AIR (0.6)
248:-
41
13683-36A00
HOSE, OVER FLOW (3X5X300)
*
42
13671-05A20
PLATE
*
43
13683-43410
HOSE (11X7X300)
*
25
13267-14D10
ADJUSTER
398:-
26
13375-14D10
SPRING
115:-
27
13427-38300
WASHER
22:-
28
13411-14E00
PLUNGER ASSY
*
29
13574-28A00
RING
*
31
09492-42010
JET, PILOT (42.5)
133:-
31
09492-35010
JET, PILOT (37.5)
175:-
31
09492-40014
JET, PILOT (40)
133:-
32
13671-48B10
CLIP
*
32
09401-10410
CLIP
34:-
33
13279-47070
SCREW, PILOT (1,1/2)
187:-
33
13279-47070
SCREW, PILOT (1,1/2)
187:-
34
13268-47070
SPRING
38:-
35
13291-29900
WASHER
17:-
37
13247-32210
CAP, DRAIN
165:-
38
13249-41310
O RING
92:-
39
09493-26004
JET, AIR (1.3)
273:-
39
09493-25003
JET, PILOT AIR (1.25)
187:-
39
09493-26004
JET, AIR (1.3)
273:-
39
09493-24007
JET, AIR (1.2)
260:-
39
09493-27002
JET, AIR (1.35)
272:-
40
09493-60004
JET, MAIN AIR (0.6)
248:-
41
13683-36A00
HOSE, OVER FLOW (3X5X300)
*
41
09352-30503-300
HOSE (3X5X300)
*
42
13671-05A20
PLATE
*
43
13683-43410
HOSE (11X7X300)
*
44
13687-32C00
HOSE (5X8X200)
*
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
