0
13200-14D03
CARBURETOR ASSY
*
0
13200-14D80
CARBURETOR ASSY
*
1
13261-27A00
CAP, TOP
*
2
13266-27A00
GASKET
60:-
7
13447-14A00
PLATE
175:-
9
13446-14A00
SPRING
*
10
13398-27A02
CONNECTOR
235:-
12
13445-14A00
GASKET, åtgår 2st
30:-
13
09160-04021
WASHER
*
14
13415-38300
E RING
20:-
15
13551-14D00
VALVE, PISTON (CA:1.5)
2160:-
16
13382-47010
.PLATE
40:-
17
13394-10010
CLIP, NEEDLE
65:-
18
13383-14D00
NEEDLE, JET (5FP96-3)
255:-
19
09494-00681
JET, NEEDLE (P-8)
*
20
13573-42A20
SPRING
165:-
21
13494-14D00
SPRING
75:-
22
13411-14D00
PLUNGER ASSY
*
23
13374-46710
O RING
50:-
24
13279-47070
SCREW, PILOT (1,1/2)
220:-
25
13268-47070
SPRING
50:-
26
13291-29900
WASHER
20:-
28
09492-35017
JET, PILOT (37.5)
240:-
29
13331-13A00
RING
55:-
30
09491-25011
JET, MAIN (127.5)
155:-
31
13370-14D10
VALVE ASSY, NEEDLE
*
34
13602-43410
SCREW
30:-
35
13250-28A00
FLOAT
335:-
36
13254-92311
PIN, FLOAT
35:-
37
13251-27A00
O RING
80:-
38
09352-30503-600
HOSE
105:-
39
13267-14D00
ADJUSTER
*
40
13331-14D00
RING
*
41
13268-14D00
SPRING
*
42
13601-04148
SCREW, åtgår 3st
30:-
43
13247-13A00
SCREW, DRAIN
75:-
44
13499-44500
BOOT
110:-
45
13487-14D00
ROD
*
46
13493-27A00
PLUNGER
95:-
47
13271-09400
SPRING
50:-
48
13613-14A00
BOLT
75:-
49
13490-14A00
LEVER
95:-
50
13553-14D00
SHAFT ASSY
*
53
13692-19C00
CLIP
*
54
09493-70009
JET, MAIN AIR,0.7
355:-
55
09493-22005
JET, PILOT AIR (1.1)
220:-
56
09404-06429
CLAMP
20:-
56
09493-20007
JET, PILOT AIR (1.0)
185:-
56
09493-22005
JET, PILOT AIR (1.1)
220:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
