1
13417-17D00
SPRING
115:-
2
13501-12D00
VALVE, PISTON
*
4
13502-12D10
COVER, DIAPHRAGM
665:-
5
09493-28007
JET, PILOT AIR (1.4)
*
6
13411-12D00
PLUNGER ASSY
355:-
7
13417-22010
SPRING
60:-
8
13418-43410
HOLDER, GUIDE
120:-
10
13258-44B00
GASKET, FLOAT CHAMBER
160:-
11
09494-00754
JET, NEEDLE (Y-2)
600:-
12
13331-07D00
RING
90:-
13
09491-27010
JET, MAIN (137.5)
160:-
14
13247-32210
CAP, DRAIN
135:-
15
13249-41310
O RING
75:-
16
13250-12E00
FLOAT/NEEDLE VALVE ASSY
*
17
13374-46710
O RING
50:-
19
13683-15A30
HOSE (6.5X10.5X500)
*
21
13331-12D00
RING
90:-
22
13394-31210
E RING
75:-
23
13387-07D00
RING
90:-
24
13383-12E00
NEELE, JET (6F6-3)
*
25
13236-12C00
FILTER
170:-
26
13247-13A00
SCREW, DRAIN
75:-
27
09492-52010
JET, PILOT (52.5)
235:-
28
13427-38300
WASHER
30:-
29
13271-24D00
SPRING
120:-
32
13278-02340
O RING
35:-
33
13684-36510
HOSE (4.5X8X250)
*
34
13684-18900
HOSE, OVER FLOW (3X5X500)
*
35
09367-06002
3 WAY CONNECTOR
45:-
36
13684-36510
HOSE (4.5X8X250)
*
31
02112-05167
SCREW, åtgår 2st
35:-
32
13278-02340
O RING
35:-
33
13684-36510
HOSE (4.5X8X250)
*
34
13684-18900
HOSE, OVER FLOW (3X5X500)
*
35
13279-47070
SCREW, PILOT (1,1/2)
220:-
35
13279-47070
SCREW, PILOT (1,1/2)
220:-
36
13268-47070
SPRING
50:-
37
13291-29900
WASHER
20:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
