1
24121-44B01
COUNTERSHAFT (NT:13)
*
3
24231-44B01
GEAR, 3RD DRIVE (NT:20)
*
4
24241-44B01
GEAR, 4TH DRIVE (NT:23)
1580:-
8
09167-25021
WASHER, 3RD DRIVEN
50:-
9
08211-25351
WASHER
45:-
10
09380-25003
CIRCLIP, åtgår 2st
50:-
11
09380-25013
CIRCLIP, 2ND DRIVE
55:-
13
09263-17026
BEARING, LH
840:-
14
24741-44B00
HOLDER, BEARING,RHH
*
16
24742-44B00
RETAINER, IDLE SHAFT, LH
65:-
18
24131-44B00
DRIVESHAFT
*
19
24311-44B00
GEAR,1ST DRIVEN (NT:32)
*
22
08211-22341
WASHER, LH
50:-
24
09300-28002
BUSH, 2ND DRIVEN
230:-
25
08211-28361
WASHER
65:-
27
24331-44B00
GEAR, 3RD DRIVEN (NT:24)
*
28
24332-27A00
BUSH, 3DR DRIVEN GEAR
200:-
29
09167-28001
WASHER (28.1X38X1.0)
60:-
30
09167-28002
LOCK WASHER, LH
60:-
31
09169-28001
LOCK WASHER, RH
50:-
33
24351-44B01
GEAR, 5TH DRIVEN (NT:20)
*
34
09262-20059
BEARING, RH (20X42X12)
430:-
36
09283-25076
SEAL, OIL
160:-
37
24751-14A00
HOLDER, OIL SEAL
*
39
27511-44B00
SPROCKET (NT:15)
*
40
27512-44B00
PLATE (YELLOW)
105:-
41
27517-37400
DAMPER
230:-
42
09111-06039
BOLT, åtgår 3st
95:-
43
27600-44B10-116
CHAIN,DRIVE (520VLX116LE) DID
2860:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
