1
24121-46001
COUNTERSHAFT (NT:15)
1410:-
2
24220-46000
GEAR, 2ND DRIVE (NT:19)
515:-
3
24231-46001
GEAR, 3RD DRIVE (NT:22)
997:-
4
24241-46000
GEAR, 4TH DRIVE (NT:24)
515:-
6
09380-17007
CIRCLIP
25:-
7
24131-46000
DRIVE SHAFT
1070:-
8
24310-46001
GEAR, 1ST DRIVEN (NT:35)
647:-
9
24321-46001
GEAR, 2ND DRIVEN (NT:32)
674:-
10
24331-46000
GEAR, 3RD DRIVEN (NT:29)
900:-
11
24341-46000
GEAR, 4TH DRIVEN (NT:26)
585:-
12
24351-46000
GEAR, 5TH DRIVEN (NT:24)
585:-
13
09160-13006
WASHER, LIMITER ASSY THRUST
28:-
14
09380-17007
CIRCLIP, åtgår 3st
25:-
15
09167-17003
WASHER (17.1X23X1.0)
34:-
16
09262-17023
BEARING, CRANKSHAFT LOWER
298:-
17
09303-13001
BUSH
73:-
18
08113-63030
BEARING, R
320:-
19
09303-13001
BUSH
73:-
20
09283-21003
OIL SEAL (21X40X6)
93:-
21
24741-46000
HOLDER, BEARING
49:-
24
26260-46001
GEAR, KICK IDLE (NT:26) (N,TN,T)
507:-
25
08211-12261
WASHER
28:-
27
27511-46700
SPROCKET, ENGINE (NT:12)
197:-
28
09180-17008
SPACER (17X21X13) (M12MARK2,M15D,M12 OD=21(0.(0.67) W=13(0.51))
104:-
29
09140-16002
NUT, CLUTCH HOUSING
40:-
30
09167-16001
WASHER (16.1X33X0.8) (M12MARK2,M15D,M12 OD=33(1.(0.51) T=1.0(0.0
27:-
31
09280-17001
O RING (D:1.0,ID:16.8)
22:-
32
27600-27412
CHAIN, DRIVE (DID428X96L)
284:-
32
27600-20910-112
CHAIN, DRIVE (DID428X112L)
402:-
33
27620-20910
JOINT (DID)
*
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
