1
25211-44001
FORK, GEAR SHIFTING NO. 1
1357:-
2
25221-44001
FORK, GEAR SHIFTING NO. 2
1357:-
3
25231-44000
FORK, GEAR SHIFTING NO. 3
1357:-
4
25411-18900
SHAFT, GEAR SHIFTING FORK
253:-
5
02142-06107
SCREW
33:-
6
08211-06141
WASHER
27:-
7
25311-01D00
CAM, GEAR SHIFTING
2537:-
8
09261-04001
PIN (4X18.5), åtgår 5st
20:-
9
09209-04013
PIN
74:-
10
09181-26001
WASHER (26X32.5X0.3)
45:-
11
25322-44000
HOLDER, DRIVE PIN
50:-
13
25341-33300
GUIDE, CAM
125:-
14
09111-06019
BOLT
*
14
09111-06054
BOLT
44:-
16
09263-40001
BEARING (40X47X12)
513:-
17
25350-44000
STOPPER, CAM NO. 1
227:-
18
09443-09007
SPRING
229:-
19
25351-30010
STOPPER, CAM NO. 2
89:-
20
25354-30000
HOLDER, SPRING
135:-
21
09440-06020
SPRING
228:-
22
09168-14004
GASKET (14.1X18X1.5) (M12MARK2,M15D,M12 2 PCSO.M10-152331)
37:-
22
09168-14002
GASKET (13.8X18.8X0.4)
42:-
23
25510-44100
SHAFT, GEAR SHIFTING
1517:-
24
09448-13008
SPRING
228:-
26
09444-26013
SPRING
40:-
27
09180-12068
SPACER (12X20X15.3)
40:-
30
25600-01D02
LEVER ASSY, GEAR SHIFTING
430:-
31
25652-20C00
RUBBER, GEAR SHIFT PEDAL
74:-
33
37720-47D00
BASE ASSY, TERMINAL
1847:-
35
02112-75203
SCREW, åtgår 2st
28:-
36
09209-05011
CONTACT
27:-
37
09440-04010
SPRING (00; ID=3.4(0.13) D=0.L=12.5(0.49))
20:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
