1
25211-44001
FORK, GEAR SHIFTING NO. 1
1357:-
2
25221-44001
FORK, GEAR SHIFTING NO. 2
1357:-
3
25231-44000
FORK, GEAR SHIFTING NO. 3
1357:-
7
09261-04001
PIN (4X18.5), åtgår 5st
20:-
8
09209-04013
PIN
74:-
9
25322-44000
HOLDER, DRIVE PIN
50:-
11
25341-44000
GUIDE, ARM
*
12
09111-06019
BOLT
*
14
09263-40001
BEARING (40X47X12)
513:-
15
25350-44000
STOPPER, CAM NO. 1
227:-
16
09443-09007
SPRING
229:-
17
25351-30010
STOPPER, CAM NO. 2
89:-
18
25354-30000
HOLDER, SPRING
135:-
19
09440-06014
SPRING
*
20
09168-14004
GASKET (14.1X18X1.5) (M12MARK2,M15D,M12 2 PCSO.M10-152331)
37:-
21
25510-47000
SHAFT, GEAR SHIFTING
*
24
09443-07013
SPRING
33:-
26
09180-12068
SPACER (12X20X15.3)
40:-
28
09162-08005
LOCK WASHER
*
32
25525-47000
ROD, LINK
247:-
34
09140-06011
NUT
19:-
35
25600-47000
LEVER ASSY, GEAR SHIFTING
699:-
37
09160-12011
WASHER (12.5X20X1) (M12MARK2,M15D,M12; O.D.=25D.=12.5(0.49) T.=1
23:-
39
37720-45100
BODY, SWITCH
1130:-
44
09209-05011
CONTACT
27:-
45
09440-04010
SPRING (00; ID=3.4(0.13) D=0.L=12.5(0.49))
20:-
