2
24221-43400
GEAR, 2ND DRIVE (NT:18)
1445:-
3
09380-25006
CIRCLIP
25:-
4
24231-43401
GEAR, 3/4 DRIVE (NT:21/23)
2100:-
6
24322-19F00
BUSH, 2ND DRIVEN
263:-
7
09380-25003
CIRCLIP
45:-
8
24261-43401
GEAR, 6TH DRIVE (NT:23)
*
9
09167-25012
WASHER
40:-
10
09380-25003
CIRCLIP
45:-
11
09267-25008
BEARING, RH
*
12
09390-58001
C-RING, CNTR SHAFT BRG, R
38:-
13
09285-20006
SEAL, OIL
84:-
14
09263-20049
BEARING, CNTR SHAFT, LH
1109:-
15
04221-07129
PIN
25:-
17
02122-06167
SCREW, åtgår 3st
21:-
20
08211-20341
WASHER, RH
30:-
21
24321-43400
GEAR, 2ND DRIVEN (NT:32)
1735:-
22
24322-19F00
BUSH, 2ND DRIVEN
263:-
23
09380-25003
CIRCLIP
45:-
24
24330-43401
GEAR, 3RD DRIVEN (NT:29)
2250:-
25
09167-25012
WASHER
40:-
26
09167-25013
LOCK WASHER, 3RD DRIVEN
37:-
27
09380-25003
CIRCLIP
45:-
28
24340-43400
GEAR, 4TH DRIVEN (NT:27)
*
29
09167-25012
WASHER
40:-
30
09169-25001
WASHER, 3RD DRIVEN LOCK
29:-
31
09380-25003
CIRCLIP
45:-
32
24351-43401
GEAR, 5TH DRIVEN (NT:23)
*
33
24361-43402
GEAR, 6TH DRIVEN (NT:22)
*
34
09262-25105
BEARING, LH (25X62X17)
1313:-
35
09390-62012
C RING, CNTR SHAFT BRG RH
99:-
36
09283-33002
OIL SEAL
*
37
09263-20040
BEARING, DRIVE SHAFT RH
865:-
38
04221-07209
PIN, DRIVE SHAFT BRG RH
27:-
39
27510-21E00
SPROCKET, ENGINE (NT:14)
*
41
09280-25001
O RING (D:1.0,ID:24.5)
43:-
42
27519-45201
SPACER
470:-
43
09159-20004
NUT, ENGINE SPROCKET
212:-
44
09167-25019
WASHER (25X40X1.4)
28:-
45
27600-19C00-112
CHAIN, DRIVE (DID50VA2)
3870:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
