34
08211-25383
WASHER, LH
*
35
09167-28001
WASHER (28.1X38X1.0)
60:-
37
24341-45100
GEAR, 4TH DRIVEN (NT:27)
2440:-
38
24331-49202
GEAR 3RD DRIVEN
2370:-
39
24332-49000
BUSH, 2ND DRIVEN GEAR
230:-
40
09167-28001
WASHER (28.1X38X1.0)
60:-
42
09169-28001
LOCK WASHER, RH
50:-
43
09167-28002
LOCK WASHER, LH
60:-
46
08211-20341
WASHER, RH
40:-
47
09262-20049
BEARING, RH
690:-
48
09390-47003
C RING
35:-
49
09380-20007
CIRCLIP, ENGINE SPROCKET
40:-
50
24761-45100
PLATE, DRIVESHAFT
*
51
24762-45000-H17
GASKET,DR SHFT
40:-
52
02122-06167
SCREW, åtgår 4st
25:-
54
09390-52002
C RING
*
55
09283-35015
SEAL, COUNTER SHAFT LH
255:-
4
09160-21010
WASHER
*
5
24250-45102
GEAR, 5TH DRIVE (NT:26)
2550:-
6
09380-32002
RING
60:-
8
24243-45101
LOCK WASHER
105:-
11
09380-32002
RING
60:-
13
24243-45101
LOCK WASHER
105:-
14
09262-25105
BEARING, LH (25X62X17)
1140:-
15
09390-62012
C RING, CNTR SHAFT BRG RH
115:-
16
24741-45000
HOLDER, BEARING
130:-
17
02122-06167
SCREW, åtgår 3st
25:-
18
09262-32003
BEARING, MIDDLE
*
20
09283-40005
OIL SEAL
345:-
22
09283-20032
OIL SEAL
*
23
08331-41326
CIRCLIP
30:-
29
09262-17023
BEARING, CRANKSHAFT LOWER
345:-
31
09241-40003
PLUG
*
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
