1
24120-33E00
SHAFT, COUNTER (NT:15)
3630:-
1
24120-33E10
SHAFT, COUNTER (NT:16)
*
2
24221-17E00
GEAR, 2ND DRIVE (NT:17)
1555:-
2
24221-33E50
GEAR, 2ND DRIVE (NT:20)
1535:-
3
24231-33E00
GEAR, 3RD & 4TH (NT:20/21)
2550:-
3
24231-33E50
GEAR, 3RD & 4TH (NT:23/22)
3365:-
4
24251-33E00
GEAR, 5TH DRIVE (NT:23)
*
4
24251-33E50
GEAR, 5TH DRIVE (NT:22)
*
5
24261-33E00
GEAR, 6TH DRIVE (NT:25)
*
5
24261-33E50
GEAR, 6TH DRIVE (NT:25)
2440:-
6
24262-17E10
BUSH, 6TH DRIVE GEAR
525:-
7
09262-25105
BEARING, LH (25X62X17)
1140:-
9
09285-20006
SEAL, OIL
105:-
10
09301-28001
BUSH, 3RD DRIVE GEAR
260:-
11
09380-27001
CIRCLIP, 2ND DRIVEN
30:-
12
09380-27001
CIRCLIP, 2ND DRIVEN
30:-
13
09380-27004
CIRCLIP, 2ND DRIVE
60:-
14
09390-62012
C RING, CNTR SHAFT BRG RH
115:-
15
04221-07209
PIN, DRIVE SHAFT BRG RH
30:-
16
24131-33E00
SHAFT, DRIVE
*
17
24311-33E00
GEAR, 1ST DRIVEN (NT:43)
2250:-
17
24311-33E50
GEAR, 1ST DRIVEN (NT:42)
*
18
24321-33E00
GEAR, 2ND DRIVEN (NT:35)
1885:-
18
24321-33E50
GEAR, 2ND DRIVEN (NT:39)
*
19
24331-33E01
GEAR, 3RD DRIVEN (NT:33)
2250:-
19
24331-33E50
GEAR, 3RD DRIVEN (NT:36)
*
20
24332-17E10
BUSH, 3RD DRIVEN GEAR
525:-
21
24332-17E10
BUSH, 3RD DRIVEN GEAR
525:-
22
24341-33E01
GEAR, 4TH DRIVEN (NT:30)
*
22
24341-33E50
GEAR, 4TH DRIVEN (NT:30)
*
23
24351-33E01
GEAR, 5TH DRIVEN (NT:29)
2250:-
23
24351-33E50
GEAR, 5TH DRIVEN (NT:27)
*
24
24361-33E00
GEAR, 6TH DRIVEN (NT:28)
*
24
24361-33E50
GEAR, 6TH DRIVEN (NT:28)
2340:-
25
09167-27002
WASHER, 3RD & 4TH DRIVEN
80:-
26
09262-28025
BEARING, DRIVE SHAFT, L
2370:-
27
09263-20040
BEARING, DRIVE SHAFT RH
955:-
28
09283-36008
SEAL, DRIVE SHAFT OIL
330:-
29
09300-22008
BUSH (22X27X0.5)
195:-
30
09300-28003
BUSH, 2ND DRIVEN GEAR
245:-
31
09380-27001
CIRCLIP, 2ND DRIVEN
30:-
32
09380-27001
CIRCLIP, 2ND DRIVEN
30:-
33
09380-27001
CIRCLIP, 2ND DRIVEN
30:-
34
09390-70001
C-RING, DRIVE SHAFT BRG, L
105:-
35
04221-07209
PIN, DRIVE SHAFT BRG RH
30:-
36
08211-20341
WASHER, RH
40:-
36
09181-20251
SHIM (T:1.0)
45:-
37
08211-22341
WASHER, LH
50:-
37
09181-22223
WASHER, 1ST DRIVEN LH
50:-
38
09181-28195
WASHER, RR FINAL DR GR
60:-
39
24751-33E00
RETAINER, DRIVE SHAFT
*
39
24751-33E10
RETAINER, DRIVE SHAFT
*
41
27510-21A10
SPROCKET, ENGINE (NT:16)
1215:-
41
27510-20A10
SPROCKET, ENGINE (NT:16)
950:-
42
27531-33E00
SPACER, ENGINE SPROCKET
*
44
27620-21E10
JOINT SET, DRIVE CHAIN
*
47
09159-20004
NUT, ENGINE SPROCKET
245:-
48
09181-25268
SHIM (25X36X1.5)
50:-
48
09160-25009
WASHER (25X41X3)
85:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
