1
24120-00A01
COUNTERSHAFT ASSY
*
2
24100-00811
COUNTERSHAFT (NT:14)
*
3
24221-49202
GEAR, 2ND DRIVE (NT:18)
2280:-
4
24231-49200
GEAR, 3RD DRIVE (NT:21)
*
5
24241-00A00
GEAR, 4TH DRIVE (NT:24)
*
6
09301-28001
BUSH, 3RD DRIVE GEAR
260:-
7
24251-00A00
GEAR, 5TH DRIVE (NT:26)
3550:-
9
08211-22321
WASHER
50:-
11
09164-20004
LOCK WASHER, åtgår 2st
60:-
12
09262-25051
BEARING, RH
1160:-
14
09241-47004
PLUG, COUNTERSHAFT LH
185:-
15
23117-45000
HOLDER
*
17
24741-45000
HOLDER, BEARING
130:-
20
09390-47003
C RING
35:-
21
24131-00A00
DRIVESHAFT
*
22
24311-49200
GEAR, 1ST DRIVEN (NT:35)
2565:-
23
09263-20018
BEARING
*
24
08211-20341
WASHER, RH, åtgår 2st
40:-
25
24321-00A00
GEAR, 2ND DRIVEN (NT:32)
2435:-
26
09301-28001
BUSH, 3RD DRIVE GEAR
260:-
29
24332-49000
BUSH, 2ND DRIVEN GEAR
230:-
30
09167-28001
WASHER (28.1X38X1.0)
60:-
32
09167-28002
LOCK WASHER, LH
60:-
33
09169-28001
LOCK WASHER, RH
50:-
34
24341-00A00
GEAR, 4TH DRIVEN (NT:27)
2280:-
35
24351-00A00
GEAR, 5TH DRIVEN (NT:25)
2395:-
37
09390-47003
C RING
35:-
40
09283-32027
OIL SEAL
*
41
09390-62008
C RING
35:-
42
24761-45000
PLATE
95:-
46
09180-25074
SPACER (25x32x21.6)
*
49
09280-25001
O RING (D:1.0,ID:24.5)
25:-
50
27600-00A20
CHAIN, DRIVE (630X120LE)
*
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
