1
24121-19C01
SHAFT, CNTR (NT:12)
3075:-
2
24221-27A01
GEAR, 2ND DRIVE (NT:16)
1505:-
3
24231-27A00
GEAR, 3/4TH DRIVE (NT:17/20)
2120:-
4
24251-27A01
GEAR, 5TH DRIVE (NT:22)
*
5
24261-17C02
GEAR, 6TH DRIVE (NT:21)
1795:-
6
09167-25012
WASHER
50:-
7
09262-25105
BEARING, LH (25X62X17)
1140:-
8
09263-20049
BEARING, CNTR SHAFT, LH
1110:-
9
09285-20006
SEAL, OIL
105:-
10
24322-19F00
BUSH, 2ND DRIVEN
305:-
11
09380-25003
CIRCLIP
50:-
13
09380-25013
CIRCLIP, 2ND DRIVE
55:-
14
09390-62012
C RING, CNTR SHAFT BRG RH
115:-
15
04221-07129
PIN
30:-
16
24100-20810
SHAFT, DRIVE (MODEL Y~F.NO.JS1GN7AA Y2101109)
2876:-
16
24131-20C31
SHAFT, DRIVE (MODEL YF.NO.JS1GN7AA Y2101110~MODEL K1/K2/K3)
*
17
24311-19C10
GEAR, 1ST DRIVEN (NT:37)
1710:-
18
24321-20C00
GEAR, 2ND DRIVEN (NT:33)
1730:-
19
24331-27A00
GEAR, 3RD DRIVEN (NT:28)
1960:-
20
24332-27A00
BUSH, 3DR DRIVEN GEAR
200:-
22
24341-27A01
GEAR, 4TH DRIVEN (NT:28)
1730:-
23
24351-27A00
GEAR, 5TH DRIVEN (NT:27)
1795:-
24
24361-20C01
GEAR, 6TH DRIVEN (NT:23)
1885:-
25
09167-28001
WASHER (28.1X38X1.0)
60:-
27
09167-28002
LOCK WASHER, LH
60:-
28
09169-28001
LOCK WASHER, RH
50:-
29
09263-20040
BEARING, DRIVE SHAFT RH
955:-
30
09267-25011
BEARING, DRIVE SHAFT LH
2420:-
31
09283-34005
SEAL, DRIVE SHAFT OIL
205:-
32
09300-22008
BUSH (22X27X0.5)
195:-
33
09300-28003
BUSH, 2ND DRIVEN GEAR
245:-
35
09390-62012
C RING, CNTR SHAFT BRG RH
115:-
36
04221-07209
PIN, DRIVE SHAFT BRG RH
30:-
37
09181-20251
SHIM (T:1.0)
45:-
38
09181-22223
WASHER, 1ST DRIVEN LH
50:-
39
09181-28195
WASHER, RR FINAL DR GR
60:-
40
24741-27A00
RETAINER, CNTR SHAFT
130:-
41
24751-40C01
RETAINER, DRIVE SHAFT
115:-
42
01500-0612A
BOLT, åtgår 4st
30:-
43
09126-06011
SCREW, DRIVE SHAFT (6X12), åtgår 2st
35:-
44
27510-17C10
SPROCKET, ENGINE (NT:15)
1160:-
45
27600-16G00-116
CHAIN ASSY, (RK50MFOZ1,116LE)
3110:-
46
09159-20004
NUT, ENGINE SPROCKET
245:-
47
09180-25091
SPACER, ENGINE SPROCKET
245:-
48
09181-25268
SHIM (25X36X1.5)
50:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
