1
13503-24B00
SPRING
280:-
3
13389-37400
PLATE
92:-
5
08321-21033
LOCK WASHER, åtgår 2st
18:-
6
13387-44030
RING
92:-
7
13394-31210
E RING
60:-
8
13382-44030
WASHER
54:-
9
13388-44030
SPRING
103:-
10
13383-24C60
NEEDLE, JET (5C40-2)
277:-
10
13383-24B40
NEEDLE,JET (5C16-2)
255:-
11
09494-00539
JET,NEEDLE (X-7)
503:-
11
09494-00587
JET,NEEDLE (X-6)
400:-
12
09491-45002
JET, PILOT AIR (45)
219:-
12
09491-70012
JET, PILOT AIR (70)
175:-
13
13502-37400
COVER
459:-
15
02112-05107
SCREW, REGULATOR, åtgår 4st
20:-
16
09491-25010
JET, MAIN (125)
133:-
16
09491-26011
JET, MAIN (130)
193:-
17
13382-03110
WASHER
24:-
18
09492-47013
JET, PILOT (47.5)
205:-
19
13370-37400
(13370-24C80) VALVE, NEEDLE
*
19
13370-24C80
VALVE ASSY, NEEDLE
1184:-
22
13373-39110
PLATE
110:-
24
13250-37400
FLOAT
453:-
25
13254-92311
PIN, FLOAT
30:-
29
13247-44080
SCREW
164:-
30
13246-44080
0 RING
55:-
31
13411-24C00
PLUNGER ASSY
749:-
31
13411-24B00
PLUNGER ASSY
*
32
13484-38A10
COVER
280:-
33
13481-24B00
SPRING
54:-
33
13481-38B90
SPRING
75:-
34
13480-24C00
DIAPHRAGM ASSY
1190:-
34
13480-05A10
DIAPHRAGM ASSY
1187:-
35
02112-04107
SCREW, åtgår 3st
22:-
36
13267-25D00
ADJUSTER
157:-
37
13271-93011
SPRING
*
38
13621-24B01
BRACKET
615:-
40
13269-37400
SCREW, PILOT (1,1/8)
169:-
41
13268-47070
SPRING
38:-
42
13291-29900
WASHER
17:-
44
13318-24C00
HOSE ASSY
403:-
44
13318-24B00
HOSE ASSY
*
46
13485-24B70
PIPE
965:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
