1
21200-24B12
GEAR, PRIMARY DRIVEN (NT:67)
4335:-
2
08211-22443
WASHER
50:-
3
09180-22023
SPACER (22X28X32.5)
293:-
4
21411-37401
HUB, SLEEVE
1494:-
5
09140-22009
NUT
98:-
6
09167-22005
LOCK WASHER
34:-
7
08211-22403
WASHER
55:-
9
21442-37401
PLATE, CLUTCH DRIVE NO.2
197:-
10
21471-37400
SEAT, WAVE WASHER
137:-
11
09164-00004
WASHER (110.5X119X0.9)
179:-
12
21451-14A00
PLATE, DRIVEN, åtgår 5st
104:-
13
21462-37400
DISK, PRESSURE
888:-
14
21465-37400
PLATE, RELEASE
248:-
15
09440-20016
SPRING, åtgår 4st
69:-
17
16321-24B00
GEAR, OIL PUMP DRIVE (NT:30)
788:-
18
09261-06002
ROLLER (OD:6,L:6)
20:-
19
23121-24B02
PIECE, CLUTCH PUSH
248:-
20
09262-12001
BEARING
324:-
21
09280-09005
O RING
55:-
22
23111-24B00-445
ROD, CLUTCH PUSH
98:-
22
23111-24B00-455
ROD, CLUTCH PUSH
98:-
22
23111-24B00-465
ROD, CLUTCH PUSH
98:-
23
23263-24B01
CAM, RELEASE
150:-
24
23270-24B03
ARM, RELEASE
1558:-
25
09448-13010
SPRING
228:-
26
09181-10111
WASHER (10X14X1.0)
33:-
27
09280-07004
O RING (D:1.9,ID:6.8)
20:-
