1
13577-41612
.ADJUSTER, CABLE
75:-
2
13661-16600
.NUT, CABLE ADJUSTER LOCK
50:-
3
13664-18654
PLUG, PRIMARY MAIN JET
140:-
4
13663-31010
GASKET, VALVE SEAT
30:-
5
13681-33010
BOOT
90:-
6
13573-30900
SPRING, THROTTLE VALVE
95:-
7
13693-16600
PLATE
*
10
13383-36A00
NEEDLE, JET (SEL45-2)
*
10
13383-36A00
NEEDLE, JET (SEL45-2)
*
11
13394-10010
CLIP, NEEDLE
65:-
12
13581-29500
PLATE, NEEDLE STOP
115:-
13
13551-36A00
VALVE, PISTON (CA:2.5)
*
14
09494-00499
JET, NEEDLE (P-6)
*
14
09494-00520
JET, NEEDLE (P-5)
*
15
13252-28310
FLOAT
325:-
16
13254-92311
PIN, FLOAT
35:-
17
09492-35004
JET, PILOT
*
18
13357-36A00
PLUG
75:-
19
09491-32002
JET, MAIN (160)
155:-
21
13370-11301
VALVE ASSY, NEEDLE
940:-
22
13373-39110
PLATE
110:-
24
13601-04148
SCREW, åtgår 4st
30:-
25
13267-36A00
ADJUSTER
160:-
26
13268-46010
SPRING
75:-
27
13278-02340
O RING
35:-
28
13247-05010
PLUG, DRAIN
55:-
29
13249-05010
GASKET, DRAIN PLUG
20:-
30
13269-15011
SCREW, AIR PILOT
185:-
31
13295-33010
O RING (K,LM,A,B)
50:-
32
13268-35010
.SPRING (K,L,M,A,BR)
50:-
33
13251-30520
GASKET, FLOAT CHAMBER
140:-
34
13683-36A00
HOSE, OVER FLOW (3X5X300)
*
35
13683-37420
HOSE (3.5X6.5X500)
*
37
13418-43410
HOLDER, GUIDE
120:-
38
13417-01010
SPRING
75:-
39
13411-01010
VALVE, STARTER
245:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
