3
13387-47010
RING
67:-
4
13394-10010
CLIP, NEEDLE
63:-
5
13382-44030
WASHER
54:-
6
13388-44030
SPRING
103:-
7
13383-38B90
NEEDLE, JET (5D39-3)
312:-
8
09494-00570
JET, NEEDLE (O-9)
400:-
9
09493-34002
JET, PILOT AIR (1.7)
*
10
13605-38B00
SCREW
164:-
12
13689-38A00
SPRING
147:-
15
13417-37100
SPRING
72:-
16
13418-05A10
HOLDER, GUIDE
212:-
17
13411-38B00
PLUNGER ASSY
*
18
13417-43010
SPRING
38:-
20
09492-50018
JET, PILOT (50)
288:-
21
13628-38B00
BRACKET
*
22
13422-38B00
LEVER
349:-
23
13602-05A30
SCREW, åtgår 2st
72:-
24
13332-05A20
WASHER, åtgår 2st
55:-
25
13502-38A00
COVER
610:-
26
13500-38B20
DIAPHRAGM ASSY
3814:-
27
13503-38B00
SPRING
212:-
28
13389-37400
PLATE
92:-
29
13251-38A00
O RING
142:-
30
13385-05A11
HOLDER
248:-
31
09491-25014
JET, MAIN (125)
212:-
32
13247-13A00
SCREW, DRAIN
67:-
34
13480-05A10
DIAPHRAGM ASSY
1187:-
35
13481-38B40
SPRING
93:-
36
13482-37300
PLATE
75:-
37
13601-04148
SCREW, åtgår 4st
24:-
38
13554-45C00
LEVER ASSY
*
42
13602-05A10
SCREW
32:-
43
13250-38B00
FLOAT
564:-
44
13254-20010
.PIN, FLOAT
32:-
47
13671-38A00
CLIP
185:-
48
13684-38A00
PROTECTOR (6.5X9.5X50)
*
49
13279-47070
SCREW, PILOT (1,1/2)
187:-
50
13268-47070
SPRING
38:-
51
13291-29900
WASHER
17:-
53
13573-38B30
SPRING
*
56
13671-38B00
CLIP, åtgår 2st
*
58
13692-24A00
CLIP
*
48
13684-38A00
PROTECTOR (6.5X9.5X50)
*
49
13279-47070
SCREW, PILOT (1,1/2)
187:-
49
13279-47070
SCREW, PILOT (1,1/2)
187:-
50
13268-47070
SPRING
38:-
51
13291-29900
WASHER
17:-
53
13573-38!30
SPRING
*
54
13684-38B00
HOSE
375:-
56
13671-38B00
CLIP, åtgår 2st
*
58
13692-24A00
CLIP
*
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
