1
27300-38820
FINAL BEVEL GEAR SET
*
2
08331-31526
.CIRCLIP
80:-
3
09262-28023
BEARING, FINAL DRIVE GEAR
1747:-
4
27312-24A01
STOPPER, BEARING
*
4
27312-24A02
STOPPER, FINAL DRIVE BE
830:-
5
27313-38B00
PLATE, BEARING STOPPER
78:-
6
27313-38B10
PLATE, BEARING STOPPER
78:-
7
09280-67004
O RING (D:2.1,ID:66.2)
44:-
7
09280-64003
O RING (D:3.1 ID:63.9)
83:-
8
09160-54001
WASHER, FINAL DRIVE BEARING
113:-
9
27445-24810
SHIM SET, FINAL DRIVE GEAR
310:-
10
09283-47002
SEAL, FINAL DRIVE OIL
203:-
11
27172-24A00
COUPLING, FINAL DRIVE GEAR
683:-
12
09160-16029
WASHER, DRIVE SHAFT
69:-
13
09159-16003
NUT, SEC DRIVEN BEVEL COUPLIN
49:-
15
09263-20062
BEARING, IDLE SHAFT
647:-
16
09262-85001
BEARING, FINAL DRIVEN GEAR,
2654:-
17
27327-38810
SHIM SET, FINAL DRIVE, R
1220:-
18
09289-70002
OIL SEAL
1003:-
19
09263-35004
BEARING, LH
1423:-
20
09160-35008
SHIM (35X46X0.95)
58:-
21
27329-45100
HOLDER, BEARING
110:-
23
09283-35033
OIL SEAL
228:-
24
27450-38B01
CASE, FINAL GEAR
*
25
27461-38B00
CASE, FINAL GEAR BEARING
2485:-
26
27481-38A01
STUD BOLT
199:-
29
09259-30007
PLUG, GEAR OIL FILLER
239:-
32
09168-14004
GASKET (14.1X18X1.5) (M12MARK2,M15D,M12 2 PCSO.M10-152331)
37:-
32
09168-14002
GASKET (13.8X18.8X0.4)
42:-
33
09164-10008
WASHER, åtgår 3st
22:-
34
09159-10026
NUT, åtgår 3st
80:-
35
09440-30008
SPRING, PROPELLER SHAFT
40:-
36
09381-40003
CIRCLIP
67:-
37
09283-30026
SEAL, COUPLING OIL
143:-
39
27151-38B00
SHAFT, PROPELLER
3535:-
40
27311-24A03
GEAR, FINAL DRIVE BEVEL
3435:-
41
27320-38B00
GEAR, FINAL DRIVEN BEVEL
*
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
