2
08321-21033
LOCK WASHER, åtgår 2st
18:-
3
13387-47010
RING
67:-
3
13387-45C00
RING
*
4
13394-10010
CLIP, NEEDLE
63:-
5
13382-44030
WASHER
54:-
6
13388-44030
SPRING
103:-
7
13383-45C00
NEEDLE,JET (5D64)
*
7
13383-45C50
NEEDLE, JET (5D48-3)
*
8
09494-00592
JET, NEEDLE (P-4)
610:-
8
09494-00688
JET,NEEDLE (P-6)
*
8
09494-00588
JET, NEEDLE (P-2)
*
8
09494-00688
JET,NEEDLE (P-6)
*
9
13605-38B00
SCREW
164:-
10
13602-19B50
SCREW, åtgår 2st
47:-
11
13684-19C00
HOSE
*
15
13418-43410
HOLDER, GUIDE
103:-
16
13411-01400
PLUNGER ASSY
187:-
17
13417-22010
SPRING
49:-
18
09492-65005
JET, PILOT AIR (65)
140:-
19
09492-40021
JET, PILOT (40)
288:-
20
13268-47070
SPRING
38:-
22
13291-29900
WASHER
17:-
23
13279-47070
SCREW, PILOT (1,1/2)
187:-
23
13279-47070
SCREW, PILOT (1,1/2)
187:-
23
13279-47070
SCREW, PILOT (1,1/2)
187:-
23
13279-47070
SCREW, PILOT (1,1/2)
187:-
24
13502-45C10
COVER
*
24
13502-45CD0
COVER
*
25
13500-45C00
DIAPHRAGM ASSY
3122:-
25
13500-45C20
DIAPHRAGM ASSY
*
26
13503-38B00
SPRING
212:-
27
13389-37400
PLATE
92:-
28
13251-38A00
O RING
142:-
29
13385-05A11
HOLDER
248:-
30
09491-25014
JET, MAIN (125)
212:-
30
09491-20019
JET, MAIN (100)
149:-
30
09491-20011
JET,MAIN (102.5)
*
31
13247-13A00
SCREW, DRAIN
67:-
33
13480-05A10
DIAPHRAGM ASSY
1187:-
34
13481-45C10
SPRING
93:-
34
13481-37300
SPRING
75:-
35
13484-45C00
COVER
329:-
36
13601-04148
SCREW, åtgår 4st
24:-
37
08310-00047
NUT
29:-
39
13554-45C00
LEVER ASSY
*
42
13370-38B00
VALVE ASSY, NEEDLE
1192:-
42
13370-39A00
VALVE ASSY, NEEDLE
1249:-
43
13602-05A10
SCREW
32:-
44
13250-38B00
FLOAT
564:-
45
13254-20010
.PIN, FLOAT
32:-
46
02112-05127
SCREW, åtgår 4st
30:-
47
13523-46110
WASHER
30:-
49
13415-38300
E RING
19:-
50
13573-38B30
SPRING
*
51
09493-24007
JET, AIR (1.2)
260:-
51
09493-26004
JET, AIR (1.3)
273:-
52
13485-45C00
RING
*
53
13684-38B00
HOSE
375:-
57
13218-45C00
HOSE ASSY
*
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
