1
13500-38A10
DIAPHRAGM ASSY
3355:-
1
13500-45C10
DIAPHRAGM ASSY
*
1
13500-45C30
DIAPHRAGM ASSY
*
2
13503-38B00
SPRING
212:-
4
08321-21033
LOCK WASHER, åtgår 2st
18:-
5
13387-47010
RING
67:-
5
13387-45C00
RING
*
6
13394-10010
CLIP, NEEDLE
63:-
7
13388-44030
SPRING
103:-
8
13389-37400
PLATE
92:-
9
13502-45C00
COVER
*
9
13502-45CE0
COVER
664:-
10
13251-38A10
GASKET
158:-
11
13382-44030
WASHER
54:-
12
09492-47013
JET, PILOT (47.5)
205:-
12
09492-45016
JET, PILOT (45)
193:-
13
13383-45C10
NEEDLE, JET (5F109-3)
245:-
13
13383-45C40
NEEDLE (5F107-3)
*
14
09491-27009
JET, MAIN (135)
197:-
14
09491-26012
JET, MAIN (132.5)
193:-
14
09491-21014
.JET, MAIN (107.5)
193:-
14
09491-22016
JET, MAIN (110)
193:-
16
09494-00712
JET,NEEDLE (P-4)
*
16
09494-00746
JET,NEEDLE (P-4)
*
17
13252-23010
FLOAT
409:-
18
13602-05A10
SCREW
32:-
19
13254-92311
PIN, FLOAT
30:-
20
13602-19B50
SCREW, åtgår 2st
47:-
21
02112-04087
SCREW, åtgår 4st
19:-
24
13370-38B00
VALVE ASSY, NEEDLE
1192:-
24
13370-39A00
VALVE ASSY, NEEDLE
1249:-
26
13418-43410
HOLDER, GUIDE
103:-
27
13417-22010
SPRING
49:-
28
13411-01400
PLUNGER ASSY
187:-
29
13279-47070
SCREW, PILOT (1,1/2)
187:-
29
13279-47070
SCREW, PILOT (1,1/2)
187:-
29
13279-47070
SCREW, PILOT (1,1/2)
187:-
29
13279-47070
SCREW, PILOT (1,1/2)
187:-
30
13268-47070
SPRING
38:-
32
13291-29900
WASHER
17:-
33
13484-45C00
COVER
329:-
34
13480-05A10
DIAPHRAGM ASSY
1187:-
35
13481-45C10
SPRING
93:-
35
13481-37300
SPRING
75:-
37
13692-02500
CLIP
137:-
39
09492-70004
JET, PILOT AIR (70)
205:-
40
13602-05A30
SCREW
72:-
41
13554-45C00
LEVER ASSY
*
41
13554-45C20
LEVER ASSY
679:-
43
13601-04148
SCREW, åtgår 4st
24:-
44
13247-13A00
SCREW, DRAIN
67:-
46
13271-93011
SPRING
*
47
13523-46110
WASHER
30:-
48
13277-37100
WASHER
34:-
49
09493-40003
JET, PILOT AIR (2.0)
255:-
49
09493-38003
JET,PILOT AIR,1
*
50
13485-45C00
RING
*
51
13685-45C00
NIPPLE
*
53
09403-09306
CLAMP
25:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
