1
13210-48EF0
CARBURETOR ASSY, FR
*
1
13210-48EG0
CARBURETOR ASSY, FR
*
2
02112-33073
SCREW, åtgår 2st
30:-
3
13387-47010
RING
67:-
4
13394-10010
CLIP, NEEDLE
63:-
5
13382-03110
WASHER
30:-
6
13388-44030
SPRING
103:-
7
13383-48E80
NEEDLE, JET (5C43-1)
237:-
8
09494-00901
JET, NEEDLE (P-4M)
*
9
13605-38B00
SCREW
164:-
10
02112-04107
SCREW, åtgår 2st
22:-
11
13281-05A00
PLUG
40:-
12
13683-19B80
HOSE (5X8X650)
314:-
13
13689-38A00
SPRING
147:-
16
13418-38A00
HOLDER, GUIDE
199:-
17
13411-01400
PLUNGER ASSY
187:-
18
13417-08210
SPRING
72:-
19
09492-65005
JET, PILOT AIR (65)
140:-
20
09492-40021
JET, PILOT (40)
288:-
21
13502-38A00
COVER
610:-
23
13503-38B00
SPRING
212:-
24
13389-37400
PLATE
92:-
26
13251-38A00
O RING
142:-
27
13385-05A11
HOLDER
248:-
28
09491-90011
JET, MAIN (90)
307:-
29
13247-02340
SCREW, DRAIN
48:-
31
13480-05A10
DIAPHRAGM ASSY
1187:-
32
13481-45C10
SPRING
93:-
33
13484-38A00
COVER
369:-
34
13602-48B10
SCREW, åtgår 4st
32:-
35
08310-00047
NUT
29:-
37
13554-45C20
LEVER ASSY
679:-
38
13376-19F00
FILTER
94:-
39
13374-35C00
O RING
54:-
40
13370-39A00
VALVE ASSY, NEEDLE
1249:-
41
13602-05A10
SCREW
32:-
42
13250-38B00
FLOAT
564:-
43
13254-20010
.PIN, FLOAT
32:-
44
02112-05127
SCREW, åtgår 4st
30:-
45
13523-46110
WASHER
30:-
46
09125-05122
SCREW
47:-
47
13683-19B80
HOSE (5X8X650)
314:-
48
13415-38300
E RING
19:-
49
13279-47070
SCREW, PILOT (1,1/2)
187:-
50
13268-47070
SPRING
38:-
52
13291-29900
WASHER
17:-
53
13331-33E00
RING
80:-
54
13602-48E00
SCREW
55:-
55
13627-48E00
BRACKET, NO.1
*
56
13627-48E10
BRACKET, NO.2
225:-
57
13683-48E10
HOSE ASSY (5X8X125)
*
58
13683-48E00
HOSE ASSY
730:-
58
13683-48E10
HOSE ASSY (5X8X125)
*
59
13641-48E00
CABLE, ID SYNCRO
434:-
60
13642-48E00
CABLE, THROTTLE RETURN, F-R
539:-
61
13684-02F10
HOSE
*
62
13685-48B00
NIPPLE
112:-
64
13590-48E00
VALVE, AIR VENT
*
65
01550-0612A
BOLT, åtgår 2st
30:-
* Kontakta kundtjänst för prisuppgift: 018-15 60 00
