1
T1260929
Kit, Clutch Cover Assy, Chromed
> ENG NO 125459
9310:-
1
T1260974
Clutch Cover Assy, Chromed
Eng No 125460 > 139276
7955:-
1
T1261231
Clutch Cover Assy
Eng No 221609 > 323213
7795:-
1
T1262025
Clutch Cover Assembly, Black
> Eng No 221608 (Plus Eng No 229407 > 230164)
9395:-
1
T1261235
Clutch Cover Assy, Black
Eng No 221609 > 372712 (Except Eng No 229407 > 230164)
8960:-
1
T1260525
Clutch Cover Assembly, Black
Eng No 372713 >
8185:-
1
T1260495
Clutch Cover Assy, Brushed
323214>(Except Eng No's 229407> 230164)
7570:-
2
T3600095
Dust Seal
40:-
3
T3800110
Bearing, Mk 1210, åtgår 2st
110:-
4
3800041-T0301
Bearing, Gearbox Lever
225:-
5
T3600008
Oil Seal
185:-
6
T3600240
Seal, oil, 14.5 28.4 6.5
> Eng No 221608 (Plus Eng. No.s 229407 > 230164)
865:-
7
T1260965
Bracket, Neut ID Lead, Ret
155:-
8
T3600143
O Ring, ID 9.1 x 1.6, Viton
> Eng No 221608 (Plus Eng. No.s 229407 > 230164)
35:-
9
T1260967
Gasket, Clutch Cover
195:-
11
T3203040
Bolt, RHHF Domed, M6 x 40, åtgår 14st
161318 > M6 x 40mm
30:-
12
T3000005
Dowel, Dia 6.0 x 16, åtgår 8st
20:-
13
T1171450
Clutch Lifter Arm
Eng No 282964-F2 / 273655-F4 >
1445:-
14
T1170931
Bullet, Clutch Lifter, Flat
> ENG NO 142537
775:-
14
T1171701
Bullet, Clutch Lifter
ENG NO 142538 >
630:-
15
T1170925
Spring return
50:-
16
T1170930
Clutch Cable Holder / Guide
> Eng No 282963-F2 / 273654-F4
195:-
16
T1171410
Clutch Cable Holder / Guide
Eng No 282964-F2 / 273655-F4 >
200:-
17
T1261932
Cover, RH, Pol, Chr
RH, >139276
3835:-
17
T1263020
Alternator Cover, Brush & Lacq
139277> 323213
3610:-
17
T1260896
Alternator Cover, Brushed & Chromate
323214>
3405:-
17
T1261957
Cover, RH, Black
RH Crinkle Black
3305:-
18
T1260968
Gasket, RH Cover
RH
145:-
19
T3203050
Bolt, Domed, S/S, M6 x 50, åtgår 11st
>161317
120:-
20
T3950100
Triumph Badge, Triangular
230:-
20
T3950105
Badge, Triumph, Triangular
For use on Black cover
220:-
21
T1261178
Plate, Wire Retainer
100:-
22
T3051062
Screw, M6 x 12, Enc, Raw
25:-
23
T1260962
Cover, G/Change Mech, Silver
> Eng No 282963-F2 / 273654-F4
2380:-
23
T1260992
Cover, Gearchange Mech, Black
Black
2195:-
24
T1260969
Gasket, Gearchange Mech Cover
160:-
25
T3205063
Bolt, RHHF, Domed, M6 x 16, S/S, åtgår 2st
60:-
26
T1261942
Sprocket Cover, Chromed
>139276
3140:-
26
T1263030
SPROCKET COVER,BRUSHED & LACQ
139277 > 323213
3055:-
26
T1260897
Sprocket Cover, Brushed & Chromate
323214 >
2875:-
26
T1262031
Sprocket Cover, Crinkle Black
2360:-
29
T3205076
Bolt, HHF, Lghtd, M6 x 1.0 x 75, Slv, åtgår 5st
> 161317 M6 x 75mm
65:-
30
T3203222
Bolt, HHF, M6 x 12, Slv, åtgår 6st
> 154062
30:-
31
T3900302
Label, Oil & Filter
F2
95:-
31
T3900302
Label, Oil & Filter
F4
95:-
32
T1260950
Breather Pipe T
> Eng no 221608 (plus eng no.s 229407 > 230164)
1765:-
33
T1260928
Plate, Sound Pad, Clutch Cover
260:-
34
T1260927
Pad, Sound Suppression
840:-
35
T3331042
Screw, Pan/Hd, Tx, M6 x 12, Enc, åtgår 8st
25:-
