1
T2108513
Kit, Radiator Cover, LH
> 227062
1785:-
1
T2108413
Radiator Cover, LH
227063 > 574812
1620:-
1
T2108435-PS
Radiator Cover, LH, Painted Black
574813 >
3455:-
2
T2108514
Kit, Radiator Cover, RH
> 226085
1785:-
2
T2108414
Radiator Cover, RH
226086 > 574812
1620:-
2
T2108436-PS
Radiator Cover, RH, Painted Black
574813 >
3455:-
3
T3330727
Screw, But/Hd, Skt, M6 x 20, S/S, åtgår 4st
> 476678
60:-
3
T3330727
Screw, But/Hd, M6 x 20, Slv, åtgår 4st
476679 >
60:-
4
T2108518
Radiator Cover, Lower
> 225059
1725:-
4
T2108418
Radiator Cover, Lower
225060 > 574812
1580:-
4
T2108440-PS
Rad Cover, Lower, Black
574813 >
3455:-
5
T3332666
Screw, But/Hd ,Skt, M6 x 1.0 x 12, S/S, åtgår 7st
75:-
6
T2100069
Cap, Radiator, Chrome
615:-
7
T3334333
Screw, Tritap, M3 x 3, Slv
110:-
8
T3332568
Screw, But/HD, M5 x 8, Slv, åtgår 6st
65:-
9
T2108417
Rad Cover, Upper
> 574812
1580:-
9
T2108439-PS
Rad Cover, Upper, Painted Black
574813 >
3455:-
10
T2107100
Grille, Radiator
Not Roadster
2380:-
10
T2100383
Grille Assy, Rad, Front, LH
Roadster Only
2830:-
11
T2107103
Kit, Grille Assy, Chrome
Not Roadster > 549211
5540:-
11
T2107101
Grille, Rad, Rear, LH
Not Roadster - 549212 >
2790:-
11
T2100381
Grille, Rad, Rear, LH, Black
Roadster Only
2830:-
12
T2107103
Kit, Grille Assy, Chrome
Not Roadster > 549211
5540:-
12
T2107102
Grille, Rad, Rear, RH
Not Roadster - 549212 >
2790:-
12
T2100382
Grille, Rad, Rear, RH, Black
Roadster Only
2830:-
13
T2100764
Pad, Foam, Radiator, åtgår 2st
65:-
14
T2108308
Fan Assembly
6930:-
15
T3331517
Screw, P/HD Tx, Shld, M6 x 16, S, åtgår 3st
20:-
16
T2108307
Radiator Assembly
17655:-
17
T3021200
Grommet, Dia 14x4, Panel, åtgår 4st
55:-
18
T3010701
Flanged Sleeve, 6.4 x 10 x 14.5, åtgår 3st
90:-
19
T3350091
Nut, Captive, M6, åtgår 2st
45:-
20
T3550603
Washer, 6.5 x 20 x 2, åtgår 3st
10:-
21
T3205083
Bolt, HHF, LGHTD, M6 x 28, Slv, åtgår 3st
45:-
22
T2108309
Bracket, Radiator, Lower, LH
115:-
23
T3331042
Screw, Pan/Hd, Tx, M6 x 12, Enc, åtgår 2st
25:-
24
T3010400
COMPRESSION LIMITER,M6, åtgår 9st
214510 > (11 required > 214509 9 Required 214510>225059 4 Required 225060>226086 2 Required 226086>227062 0 Required 227063>)
75:-
24
T3551290
Washer, Nylon, 14.0 x 6.4 x 1.2, åtgår 3st
225060 > 226085 (5 required 226086 > 227062, 7 Required 227063 >)
75:-
25
T3660171
Pad, Rubber, 30 x 10 x 5, thick, åtgår 2st
346237 >
135:-
26
T2108319
Bracket, Radiator, Lower, RH
115:-
27
T3351021
Nut, Captive, M6, Slv
> 237880
30:-
29
T3550188
Washer, Foam, åtgår 2st
214510 >
75:-
30
T3330727
Screw, But/Hd, M6 x 20, Slv, åtgår 2st
60:-
31
T3550213
Washer, Plastic, M6, åtgår 2st
20:-
