1
T2301892-MH
Sidepanel Front, LH
Aluminium Silver
18510:-
1
T2301892-JI
Sidepanel, Front, LH
Pacific Blue
18510:-
1
T2301892-PR
Sidepanel, Front, LH
Phantom Black
18510:-
1
T2301892-GJ
Sidepanel Front, LH
Champagne - 593165 > 657552
18510:-
1
T2303892-CX
Sidepanel, Front, LH
Cranberry Red - 593165 >
18510:-
1
T2303892-JD
Sidepanel, Front, LH
Caspian Blue - 657553 >
18510:-
2
T2301893-MH
Sidepanel, Front, RH
Aluminium Silver
18510:-
2
T2301893-JI
Sidepanel, Front, RH
Pacific Blue
18510:-
2
T2301893-PR
Sidepanel, Front, RH
Phantom Black
18510:-
2
T2301893-GJ
Sidepanel, Front, RH
Champagne - 593165 > 657552
18510:-
2
T2303893-CX
Sidepanel, Front, RH
Cranberry Red - 593165 >
18510:-
2
T2303893-JD
Sidepanel, Front, RH
Caspian Blue - 657553 >
18510:-
3
T2301515
Foam Pad, Lh Sidepanel, Upper
220:-
4
T2301575
Foam Pad, Rh Sidepanel
385:-
5
T2301504
Foam Pad, RH Sidepanel, Lower
205:-
6
T2301579
Pad, Heat Shield
360:-
7
T2301586
Radiator Infill, Lh
1705:-
8
T2301587
Radiator Infill, Rh
1705:-
9
T2302119
Oil Cooler Infill
1440:-
10
T2306889
Bracket, LH, B/work & Regulator
> 523249
100:-
10
T2306889
Brkt, LH Bodywork & Regulator
523250 >
100:-
11
T2301592
Bracket, Lh, Upper Rear
95:-
12
T2309597
Bracket, RH, Upper Bodywork, Relays
210:-
13
T2301594
Bracket, Lh, Lower, Rear
105:-
14
T2301593
Bracket
105:-
15
T3205063
Bolt, RHHF, M6 x 16, Silver, åtgår 4st
60:-
16
T3020153
Grommet, 13 x 3 x 10, åtgår 2st
35:-
17
T3331063
Bolt, But/Hd, M5 x 17, Slv, åtgår 4st
35:-
18
T3330941
Screw, But/Hd, Skt, M5 x 16, Slv, åtgår 6st
110:-
19
T2301526
Trim, Sidepanel, Vent, åtgår 2st
> 593164
920:-
19
T2305538-PS
Trim, Sidepanel Vent, Matt Black, åtgår 2st
593165 >
2135:-
21
T3551139
Washer, Retaining, 3.18 x 9.50, Slv, åtgår 4st
50:-
22
T3350123
Nut, Captive, M5, Non-Secured, åtgår 3st
45:-
23
T3205066
Bolt, HHF, Lghtd, M6 x 20, Slv
75:-
24
T3205063
Bolt, RHHF, M6 x 16, Silver, åtgår 2st
60:-
25
T3350111
Nut, Captive, M6
85:-
26
T3600151
O Ring, åtgår 4st
45:-
27
T3020019
Grommet, Split, Rubber
30:-
28
T3351052
Nut, Captive, 4-5.5mm, åtgår 13st
75:-
29
T2301627
Pad, Heat Shield, Left
345:-
30
T2301628
Pad, Heat Shield, Right
345:-
31
T2301503
Foam Pad, LH Sidepanel, Lower
215:-
32
T3331064
Bolt, But/Hd, M5 x 17, Shld, Enc, åtgår 2st
130:-
33
T2301534
Pad, Foam, Fairing, LH
350:-
34
T2301535
Pad, Foam, Fairing, RH
350:-
35
T3555023
Washer, 5.3 x 18 x 1.6, åtgår 2st
25:-
