3
T3600210
O ring
25:-
5
T3331102
Bolt, HHF, M6 X 25, S/S, åtgår 2st
M6 x 25mm
50:-
6
T3600200
O ring
65:-
7
T3550542
Washer, Cu, Od12.5 x Id6.4
20:-
9
T2100074
Cap Assy
465:-
10
T3331043
Screw, Pan/Hd, Tx, M6 x 12, Slv, åtgår 5st
20:-
12
T3205066
Bolt, HHF, Lghtd, M6 x 20, Slv
75:-
13
T2100405
Elbow, ID 8.0 Tube, åtgår 2st
25:-
14
T3021200
Grommet, Dia 14x4, Panel, åtgår 3st
55:-
15
T2100997
Cap, Expansion Tank
Expansion tank
165:-
16
T3620320
Pipe, Expansion Tank, Internal
30:-
17
T3620300
Overflow pipe, åtgår 2st
210:-
18
T3700440
Clip, Hose, 11-12.5mm
90:-
19
T3700077
Clip, 10.5 Rer Oetiker
70:-
20
T3450035
Grommet, Dia 8, Dia 12.5, 3
35:-
22
T2100509
Water pump assy
4000:-
23
T3600230
Seal
95:-
24
3600160-T0301
O Ring, Water Pump
150:-
25
T3205075
Bolt, HHF, Lghtd, M6 x 65, Slv, åtgår 2st
65:-
27
T2100110
Hose outlet
390:-
28
T2102143
Gasket
» ENG NO 111880
25:-
28
T3600185
O ring
ENG NO 111881 »
45:-
29
T3330334
Screw, Tx, Pan/HD, M6 x 16, Slv, åtgår 2st
» ENG NO 111880
45:-
29
T3331234
Screw, Torx, P/H, M6 x 20, Slv, åtgår 2st
ENG NO 111881 »
90:-
30
T2100192
Hose
Cylinder Head To Thermostat
1110:-
33
T2102392
Hose bottom
Radiator to Pump
350:-
34
T2102242
Hose Clip, 23-25, Bright, Ss, åtgår 8st
130:-
35
T3700171
Clip hose
115:-
36
T2102112
Clip hose
80:-
37
T3555004
Washer, 6.4 x 14 x 1.6, åtgår 7st
25:-
38
T2101241
Fan
8205:-
39
T2100670
Radiator
17100:-
42
T3205083
Bolt, HHF, LGHTD, M6 x 28, Slv, åtgår 2st
45:-
43
T3010710
Flanged Sleeve, 6.4 x 9.6 x 13.4, åtgår 4st
60:-
45
T3350012
Locknut, Flgd, M6, Black, Zinc, åtgår 3st
20:-
46
T2100807
Sensor, Coolant Temp
1040:-
47
T3550571
Washer, Cu, OD 16 x ID 12.5
20:-
48
T3010014
Flanged Sleeve, M6, Black, åtgår 2st
25:-
50
T3700044
Guide, Cable (Wire Guide)
Clutch Cable
185:-
51
T3700047
Wire Guide
Throttle Cable
140:-
