2
T2100166
Radiator, Curved
15175:-
3
T2100274
Fan, Cooling, 170 Dia
6750:-
4
T3331517
Screw, Torx Ph Shld, M6 x 16, Blk
20:-
5
T2100164
Cap Assy, Radiator
325:-
6
T2100084
Bleed Screw, Nylon
130:-
7
T3450124
Cap
95:-
8
T3350012
Locknut, Flgd, M6, Black, Zinc
> 438089
20:-
8
T3350003
Locknut, Flanged, M6 x 1.0
438090 >
20:-
9
T3205066
Bolt, RHHF, Domed, M6 x 20, S/S
> 462676
75:-
9
T3205066
Bolt, HHF, Lghtd, M6 x 20, Slv
462677 >
75:-
10
T3010702
Flanged Sleeve, 6.4 x 10 x 8.5
95:-
11
T3020153
Grommet, 13 x 3 x 10, åtgår 2st
35:-
12
T3203030
Bolt, RHHF, Domed, M6 x 30
> 484789
55:-
12
T3205070
Bolt, HHF, Lghtd, M6 x 30, Slv
484790 >
35:-
14
T2105119
Coolant Hose, Rad to Pump
535:-
15
T3707580
Hose Clip, Dia 20-32, åtgår 4st
150:-
16
T2100407
Hose, Water Pump Outlet
> Eng No 519946 - Sump Cover Gasket also required
385:-
16
T2105201
Hose, Water Pump, Outlet
Eng No 519947 >
475:-
17
T2107016
Kit, Water Pump Outlet
> Eng No 519946 - Sump Cover Gasket also required
1055:-
17
T2107013
Pipe, Water Pump Outlet
Eng No 519947 >
655:-
18
T3600190
O Ring, 24 x 2.5
20:-
19
T3200444
Bolt, M6 x 10
180:-
20
T3551111
Copper Washer, M6 x 12
40:-
21
T2105114
Hose, Coolant, HE to Rad
540:-
22
T2105111
Hose, Coolant, Pump Outlet
365:-
23
T3707570
Hose, Clip Dia 12-22, åtgår 4st
170:-
24
T2100408
Hose, Bypass, Water
200:-
25
T3700440
Clip, Hose, 11-12.5mm, åtgår 3st
90:-
26
T2107012
Pipe, Water Pump Inlet
655:-
27
T3205064
Bolt, RHHF, Domed, M6 x 16, S/S, åtgår 2st
65:-
28
T3600124
O Ring, ID 21.5 x 3, åtgår 3st
60:-
29
T2100206
Cover, Water Outlet
855:-
30
T2100201
Seal, Thermostat
110:-
31
T2100675
Thermostat
1070:-
32
T3205066
Bolt, HHF, Lghtd, M6 x 20, Slv, åtgår 2st
75:-
33
T2100224
Cover, Water Inlet
535:-
34
T2100205
Gasket, Water Inlet
55:-
35
T3205066
Bolt, HHF, Lghtd, M6 x 20, Slv, åtgår 2st
Eng No 464433 > (F2) & Eng 467003 > (F4)
75:-
36
T2100168
Bracket, Radiator, Lower, Rear
150:-
37
T3331102
Bolt, HHF, M6 X 25, S/S
> Eng No 463158 (F2) & > Eng No 475641 (F4)
50:-
37
T3205067
Bolt, HHF, Lghtd, M6 x 25, Slv
Eng No 463159 > (F2) & Eng No 475642 > (F4)
45:-
38
T2100169
Bracket, Radiator, Lower, Front
145:-
39
T3205067
Bolt, RHHF, M6 x 25, Slv
45:-
41
T3205063
Bolt, HHF, Lghtd, M6 x 16, Slv
60:-
42
T2105118
Hose, Coolant, Rad to Thermostat
630:-
43
T3707585
Clip, Hose, Dia 27-35, åtgår 2st
80:-
44
T3330676
Screw, Bleed, Plastic, M6 x 16
130:-
45
T3550231
Rubber Washer, M6 x 12
30:-
46
T2102200
Expansion Tank
1180:-
47
T2101015
Cap, Expansion Tank
35:-
48
T2501750
Battery Strap
155:-
49
T3620551
Hose, Coolant, Formed End, åtgår 2st
510:-
50
T2102012
Hose Cover
220:-
51
T3700077
Clip, 10.5 Rer Oetiker
70:-
52
T3701098
Firtree, Dia 5 x 18
90:-
53
T3555026
Washer, 6.4 x 18 x 1.6
20:-
54
T3350012
Locknut, Flgd, M6, Black, Zinc
> 438457
20:-
54
T3350003
Locknut, Flanged, M6 x 1.0
438458 >
20:-
55
T2100563
Radiator Cowl, LH
1130:-
56
T2100564
Radiator Cowl, RH
1130:-
57
T3331061
Bolt, But/Hd, M5 x 11, Shld, Slv, åtgår 4st
> 457277
80:-
57
T3331075
Bolt, But/Hd, M5 x 14, Slv, åtgår 4st
457278 >
80:-
58
T2100608
Bracket, Radiator Cowl, LH
120:-
59
T3202304
Bolt, RHHF, M6 x 20, Slv
90:-
60
T2100609
Bracket, Radiator Cowl, RH
120:-
61
T3205063
Bolt, HHF, Lghtd, M6 x 16, Slv, åtgår 2st
60:-
62
T3330749
Screw, But/HD, Shld, M5 x 16, åtgår 2st
> 457277
60:-
62
T3331062
Bolt, But/Hd, M5 x 16, Shld, Slv, åtgår 2st
457278 >
105:-
63
T3450108
Stand Off Rubber, åtgår 2st
45:-
64
T2100379
Quickfit Grommet Kit
> 437990
140:-
64
T3450141
Grommet, TPE, Quickfit
437991 >
35:-
65
T2100433
Elbow, Overflow, Quickfit
100:-
