2
T2100308
Radiator, Flat
17780:-
3
T2100309
Fan, Cooling
6090:-
4
T2100164
Cap Assy, Radiator
325:-
5
T2100084
Bleed Screw, Nylon
130:-
6
T3331517
Screw, Torx Ph Shld, M6 x 16, Blk, åtgår 3st
20:-
8
T3205066
Bolt, HHF, Lghtd, M6 x 20, Slv
75:-
9
T3010702
Flanged Sleeve, 6.4 x 10 x 8.5
95:-
10
T3020153
Grommet, 13 x 3 x 10, åtgår 2st
35:-
11
T2100422
Hose, Water Inlet, T-Piece
525:-
12
T3707580
Hose Clip, Dia 20-32, åtgår 4st
> 632887
150:-
12
T3706214
Clamp, Constant Tension, Dia 29, åtgår 4st
632888 >
200:-
13
T3707570
Hose, Clip Dia 12-22, åtgår 3st
> 632887
170:-
13
T3706211
Clamp, Constant Tension, Dia 19, åtgår 3st
632888 >
260:-
14
T2100423
Hose, Water Inlet, Heat Ex
385:-
15
T2100407
Hose, Water Pump Outlet
> Eng No 526038
385:-
15
T2105201
Hose, Water Pump, Outlet
Eng No 526039 >
475:-
16
T2107017
Kit, Water Pump Outlet
> Eng No 526038
1055:-
16
T2107014
Pipe, Water, Pump Outlet
Eng No 526039 >
655:-
17
T3600190
O Ring, 24 x 2.5
20:-
18
T3205064
Bolt, RHHF, Domed, S/S, M6 x 16, Enc, åtgår 2st
65:-
19
T3600124
O Ring, ID 21.5 x 3, åtgår 3st
60:-
20
T2107012
Pipe, Water Pump Inlet
> Eng No 528986
655:-
21
T2100408
Hose, Bypass, Water
200:-
22
T3700440
Clip, Hose, 11-12.5mm, åtgår 3st
90:-
23
T2108890
Hose, Expansion Tank
200:-
24
T3700108
Clip, Cable, 14.3 x 10
55:-
25
T2100424
Hose, Water, Head to Rad
555:-
26
T3330676
Screw, Bleed, Plastic, M6 x 16
130:-
27
T3550231
Rubber Washer, M6 x 12
30:-
28
T3707585
Clip, Hose, Dia 27-35
> 632887
80:-
28
T3706216
Clamp, Constant Tension, Dia 32
632888 >
200:-
29
T2100675
Thermostat
1070:-
30
T2100201
Seal, Thermostat
110:-
31
T2100206
Cover, Water Outlet
855:-
32
T3205066
Bolt, HHF, Lghtd, M6 x 20, Slv, åtgår 2st
75:-
33
T2100224
Cover, Water Inlet
535:-
34
T2100205
Gasket, Water Inlet
55:-
35
T3205066
Bolt, HHF, Lghtd, M6 x 20, Slv, åtgår 2st
75:-
36
T2108888
Expansion Tank, Coolant
1395:-
37
T2101015
Cap, Expansion Tank
35:-
38
T3450141
Grommet, TPE, Quickfit
35:-
39
T2100433
Elbow, Overflow, Quickfit
100:-
40
T3202304
Bolt, RHHF, M6 x 20, Slv, åtgår 2st
90:-
42
T2108889
Finisher, Expansion Tank
595:-
43
T3330941
Screw, But/Hd, Skt, M5 x 16, Slv
110:-
44
T2304368
Sheet, Air Dam
225:-
45
T3351052
Nut, Captive, 4-5.5mm
75:-
46
T3205063
Bolt, HHF, Lghtd, M6 x 16, Slv
60:-
47
T3205067
Bolt, HHF, Lghtd, M6 x 25, Slv
45:-
50
T2100323
Bracket, Radiator, Lower, Front
115:-
51
T2100168
Bracket, Radiator, Lower, Rear
150:-
52
T3205067
Bolt, HHF, Lghtd, M6 x 25, Slv
45:-
53
T2108895
Hose, Expansion Tank Overflow
430:-
54
T3700015
Cable Tie, 185.7 Long
20:-
55
T3700077
Clip, 10.5 Rer Oetiker
70:-
57
T3707580
Hose Clip, Dia 20-32
> 632887
150:-
57
T3706215
Clamp, Constant Tension, Dia 30
632888 >
200:-
