2
T3450005
Plug, NPSI 3/8 Dryseal, åtgår 2st
> Eng No 698316
110:-
2
T3450000
Plug, PTF-SAE Short, 3/8-18, Enc, åtgår 2st
Eng No 698617 >
105:-
3
T3450091
Plug, Dia 14, Alum
45:-
4
T3800165
Bearing, Ball, 6306R
620:-
6
T1261049
Sight glass
305:-
7
T3500078
Circlip, Int Dia 81.4 x 1.2
25:-
8
T3550542
Washer, Cu, Od12.5 x Id6.4
20:-
9
T3205062
Bolt, HHF, Lghtd, M6 x 12, Slv
70:-
10
T1222207
Bush, 10 x 12 x 8
95:-
11
T1210288
Pipe, Gearbox, Oil Feed Spray
480:-
12
T3600143
O Ring, ID 9.1 x 1.6, Viton
35:-
13
T3600252
O Ring, 10.1 x 1.6, Viton
50:-
14
T3600109
O Ring, ID 5.6 x 2.3
95:-
15
T3000102
Dowel, Hollow, 10 x 14, åtgår 3st
30:-
16
T1180156
Sleeve Assy, Needle bearing
1135:-
17
T1160217
Plate, Oil Retainer
75:-
18
T1160218
Gasket, Oil Retainer Plate
55:-
19
T3331042
Screw, Pan/Hd, Tx, M6 x 12, Enc, åtgår 4st
25:-
20
T3450119
Plug, Face Seal, M16 x 1.5
110:-
21
T3600191
O Ring, 16 x 2
65:-
22
T1182203
Plate, Retainer, Bearing, Input
80:-
23
T3331042
Screw, Pan/Hd, Tx, M6 x 12, Enc, åtgår 3st
25:-
24
T3555012
Washer, 6.4 x 16 x 2
60:-
25
T3331042
Screw, Pan/Hd, Tx, M6 x 12, Enc
25:-
26
T3000101
Dowel, Hollow, 8 x 14, åtgår 2st
65:-
27
T1161453
Main Bearing, Grooved, Green
Green
270:-
27
T1161451
Main Bearing, Grooved, Red
Red
270:-
27
T1161450
Main Bearing, Grooved, White
White > Eng No 728006
270:-
27
T1161452
Main Bearing, Grooved, Blue
Blue
270:-
28
T3450299
Firtree, M6, åtgår 2st
60:-
29
T2503147
Bracket, Cable Tidy
65:-
30
T1162201
Baffle Plate, Crankcase, Breather
55:-
31
T3331042
Screw, Pan/Hd, Tx, M6 x 12, Enc, åtgår 3st
25:-
32
T1162202
Gasket, Breather Plate
215:-
33
T3450101
Button, Firtree, M6 x 11
25:-
