1
T2100855
Cowl, Fan
1110:-
2
T2100854
Radiator, Curved
18415:-
3
T2100856
Fan, Cooling
6520:-
4
T2100081
Cap Assy, Radiator
230:-
5
T2100544
Hose, Radiator to Pump
770:-
6
T3706214
Clamp, Constant Tension, Dia 29, åtgår 3st
200:-
7
T2100636
Pipe, Radiator to Expansion Tank
785:-
8
T3700077
Clip, 10.5 Rer Oetiker
70:-
9
T2100910
Hose, Thermostat to Radiator
1235:-
10
T2100905
Spigot, Coolant Bleed
290:-
12
T2100909
O Ring, 11.20 x 1.78 Dia
65:-
13
T3706216
Clamp, Constant Tension, Dia 32, åtgår 3st
200:-
14
T2100906
Hose, T'Stat to Bleed Spigot
1235:-
15
T2100907
Hose, Bleed Spigot to Rad
1235:-
16
T2108355
Expansion Tank
1725:-
17
T2100461
Cover, Expansion Tank
890:-
18
T2100637
Pipe, Expansion Tank Overflow
375:-
19
T2101015
Cap, Expansion Tank
35:-
20
T2100462
Bracket, Expansion Tank
185:-
21
T3330334
Screw, Tx, Pan/HD, M6 x 16, Slv, åtgår 2st
45:-
22
T3555026
Washer, 6.4 x 18 x 1.6, åtgår 2st
20:-
23
T3700440
Clip, Hose, 11-12.5mm, åtgår 2st
90:-
24
T3331043
Screw, Pan/Hd, Tx, M6 x 12, Slv, åtgår 2st
20:-
25
T3330649
Screw, Pan/Hd, Tx, M5 x 12, Slv
80:-
27
T2100479
Cover, Water Outlet, åtgår 2st
785:-
28
T2100201
Seal, Thermostat
110:-
29
T2100676
Thermostat
1035:-
30
T3205066
Bolt, HHF, Lghtd, M6 x 20, Slv, åtgår 2st
75:-
31
T2100914
Bracket, LH, Radiator
600:-
32
T2100915
Bracket, RH, Radiator
600:-
33
T3205254
Bolt, HHF, Lghtd, M8 x20, Slv, åtgår 2st
30:-
34
T3020030
Grommet, Rubber, åtgår 2st
145:-
35
T3010052
Flanged Sleeve, M6 x 12 x 10.75, åtgår 2st
85:-
36
T3205067
Bolt, HHF, Lghtd, M6 x 25, Slv, åtgår 2st
45:-
37
T3350305
Locknut, Flgd, M6 x 1.0, Slv, åtgår 2st
35:-
38
T3021200
Grommet, Dia 14x4, Panel, åtgår 2st
55:-
39
T3010701
Flanged Sleeve, 6.4 x 10 x 14.5, åtgår 2st
90:-
40
T3200148
Bolt, M6 x 30, Silver, åtgår 2st
75:-
42
T3450299
Firtree, M6
60:-
43
T2100966
Radiator Shroud, RH
875:-
44
T2100965
Radiator Shroud, LH
875:-
45
T3331436
Screw, S/Tap, Pan, Torx, 4 x 11, PT, åtgår 3st
20:-
47
T3330891
Bolt, RHHF, M5 x 0.8 x 12, S5041, åtgår 2st
55:-
