1
T1100300
Crankshaft Assy
23845:-
2
T3552022
Washer, Thrust, 54 x 75 x 1.75
160:-
3
T1102010
Gear, Primary, Pinion, Assy
4265:-
4
T1102040
Follower, Cam, Damper, Splined
1665:-
5
T3552049
Spring, Disc, 85 x 124.5 x 3.5, åtgår 6st
245:-
6
T1103045
Retainer, Spring, Splined
2030:-
7
T3151045
Bolt, HHF, M12 x 1.25 x 45, Raw
105:-
8
T3550241
Washer, 12.3 x 60 x 11.8
105:-
9
T1113101
Assy, Con-Rod
4595:-
10
T1113102
Bolt, Con Rod, åtgår 2st
225:-
11
T1110016
Nut, Con Rod, åtgår 2st
160:-
12
T1110083
Bearing Shell, Con Rod, White, åtgår 4st
220:-
12
T1110084
Bearing Shell, Con Rod, Red, åtgår 4st
220:-
12
T1110085
Bearing Shell, Con Rod, Green, åtgår 4st
220:-
13
T1120017
Piston Assembly 103.8
10295:-
13
T1120127
Piston Assy, 107.1
1700cc Only
4760:-
14
T1120036
Piston, 103.8, Ab Grade
4390:-
14
T1120522
Piston, 107.1, Grade A/B, åtgår 2st
1700cc Only
4615:-
15
T1120029
Gudgeon Pin
195:-
15
T1120045
Gudgeon Pin, åtgår 2st
1700cc Only
810:-
16
T1120016
Circlip, Piston, åtgår 4st
60:-
17
T1120044
Piston Ring Set, åtgår 2st
2135:-
17
T1120112
Piston Ring Set, 107.1, åtgår 2st
1700cc Only
2195:-
18
T3551606
Washer, Shim,13 x 23 x 0.5
> Eng No 427424
115:-
19
T3550617
Washer, 12.5 x 22.75 x 2
65:-
20
T1120041
Ring, 1st Compression
2115:-
21
T1120042
Ring, 2nd Compression
2095:-
22
T1120043
Ring, Oil Control
2115:-
