1
T2303076-PG
Front Mudguard Assy
Jet Black > 450960
13050:-
1
T2303076-PR
Front Mudguard Assy
Phantom Black; 450961 >
13050:-
1
T2303076-JI
Front Mudguard Assy
Pacific Blue/Fusion White > 550006
9000:-
1
T2305920-MH
Front Mudguard Assy
Aluminium Silver/Jet Black > 450960
13050:-
1
T2303077-MH
Front Mudguard Assy
Aluminium Silver/Phantom Black; 450961 >
13050:-
1
T2305920-CU
Front Mudguard Assy
Carnival Red - Special Edition Only
13050:-
1
T2305920-NW
Front Mudguard Assy
Crystal White
13050:-
1
T2303076-CX
Front Mudguard Assy
Cranberry Red; 472064 > 550006
13050:-
1
T2305920-CY
Front Mudguard Assy
Marble Red Haze - 519898 >
9130:-
1
T2305919-CX
Front Mudguard Assy
Cranberry Red/Phantom Black - 550007 > 603095
9130:-
1
T2305919-JD
Front Mudguard Assy
Caspian Blue/Phantom Black - 550007 > 657552
13050:-
1
T2305920-JW
Front Mudguard Assy
Marble Blue Haze - 568250 >
13050:-
1
T2303077-CD
Front Mudguard Assy
Lava Red/Silver Frost; 603096 >
13050:-
2
T3331041
Screw, Pan/Hd, Tx, M6 x 25, Enc, åtgår 4st
20:-
3
T3020050
Grommet, åtgår 4st
85:-
4
T3010297
Compression Limiter, Id 6.5, åtgår 4st
70:-
5
T2303078-PG
Rear Mudguard Assy
Jet Black > 450960
16490:-
5
T2303078-PR
Rear Mudguard Assy
Phantom Black; 450961 >
16490:-
5
T2303078-JI
Rear Mudguard Assy
Pacific Blue/Fusion White > 550006
16490:-
5
T2306320-MH
Rear Mudguard Assy
Aluminium Silver/Jet Black > 450960
16490:-
5
T2303079-MH
Rear Mudguard Assy
Aluminium Silver/Phantom Black; 450961 >
15995:-
5
T2306320-CU
Rear Mudguard Assy
Carnival Red - Special Edition Only
16310:-
5
T2306320-NW
Rear Mudguard Assy
Crystal White/Sapphire Blue with Red Decal
16490:-
5
T2306411-NW
Rear Mudguard Assy
Crystal White/Sapphire Blue with Blue Decal
16490:-
5
T2303078-CX
Rear Mudguard assy
Cranberry Red; 472064 > 550006
16490:-
5
T2306320-CY
Rear Mudguard Assy
Marble Red Haze - 519898 > 603095
16490:-
5
T2303078-JD
Rear Mudguard Assy
Caspian Blue/Phantom Black - 550007 > 657552
16490:-
5
T2306320-JW
Rear Mudguard Assy
Marble Blue Haze - 568250 >
15705:-
5
T2303079-CD
Rear Mudguard Assy
Lava Red/Silver Frost; 603096 >
16490:-
6
T2306348
M/Guard Support, Pressing, RH
1010:-
7
T2306349
M/Guard Support, Pressing, LH
1010:-
8
T3205781
Bolt, HHF, Lghtd, M8 x 1.25 x 25, Slv, åtgår 2st
458368 >
30:-
9
T3200455
Bolt, HHF, M8 x 33, A2 S/S, åtgår 2st
N/A to Special Edition > 458361
115:-
9
T3205868
Bolt, HHF, Lghtd, M8 x 33, Slv, åtgår 2st
N/A to Special Edition - 458362 >
100:-
10
T3200452
Bolt, HHF, M10x1.25x45, A2, SS, åtgår 2st
N/A to Special Edition > 458361
135:-
10
T3205825
Bolt, HHF, Lghtd, M10 x 45, Slv, åtgår 2st
N/A to Special Edition - 458362 >
110:-
11
T3551282
Washer, M8, 8.4 x 15 x 1.6, Slv, åtgår 4st
60:-
12
T3551283
Washer, M10, 10.5x18x1.6, Slv, åtgår 2st
35:-
13
T2700827
Moulding, Reg Plate
935:-
14
T3205063
Bolt, RHHF, M6 x 16, Silver
60:-
16
T2304224
Moulding, Cover, Harness
205:-
17
T3203201
Bolt, HHF, Lghtd, M6 x 10, SS, åtgår 2st
100:-
18
T3021161
Rubber Foot, Dia 14.22 x 7.1
35:-
19
T2700443
Reflector, Oval, Red, USA, åtgår 2st
US, ZA & CA Only - N/A to Special Edition
125:-
21
T3550253
Washer, Dia 5 mm, Retaining, åtgår 2st
20:-
22
T2306032
Baffle, Rubber
> 433196
240:-
24
T2700464
Reflector, Red, Circular, åtgår 2st
Special Edition Only; US, CA, AR, ZA & TW Only
115:-
25
T2705500
Reflector Bracket, RH
Special Edition Only; US, CA, AR, ZA & TW Only
135:-
26
T3350010
Locknut, Flgd, M5, åtgår 2st
Special Edition Only; US, CA, AR, ZA & TW Only
35:-
27
T2705501
Reflector Bracket, LH
Special Edition Only; US, CA, AR, ZA & TW Only
955:-
28
T3450101
Button, Firtree, M6 x 11
25:-
29
T3600109
O Ring, ID 5.6 x 2.3, åtgår 2st
95:-
