1
T3802035
Bearing, D, Row, A, Cont. 5207
1235:-
2
T3802030
Bearing, D, Row, A, Cont. 5205
1235:-
3
T1180155
Sleeve Assembly, Input & Output
1930:-
4
T3800006
Bearing, Needle, K25x32x16
270:-
5
T1183164
Shaft, Input, Gearbox, Assy
8655:-
6
T1183100
Shaft, Input, Gearbox, 16t
5580:-
7
T1183165
Gear, Pinion, 33T, Helical, Free
3160:-
8
T1183095
Spacer, Splined, Bush, åtgår 3st
1110:-
9
T1183101
Gear, Pinion, 32t Helical, Fixed
3160:-
10
T1183015
Spacer, Splined, Gearbox
1130:-
11
T1183173
Ring, Shift, 5th/6th Gear
6790:-
12
T1183166
Gear, Pinion, 34T, Helical, Free
3160:-
13
T1183035
Gear, Pinion, 28t, Helical
2830:-
14
T1183040
Gear, Pinion, 24t, Helical
2320:-
15
T1182135
Plate, Retainer, Bearing
145:-
16
T3331044
Screw, Pan/Hd, Tx, M6 x 16, Slv, åtgår 3st
20:-
17
T1183152
Washer, Thrust, 25 x 38 x 16
80:-
18
T1183175
Shaft, Output, Gearbox, Assy.
8040:-
19
T1183110
Shaft, Output, Splined
6975:-
20
T1183111
Ring, Shift, 1st/6th Gear
6790:-
21
T1182032
Bush, 30.0 x 35.0 x 15.0
735:-
22
T1183105
Gear, Output, 46t, Spur
2850:-
23
T1182033
Washer, Thrust, 30 x 46 x 1.60
65:-
24
T3800260
Bearing, 6206, 30x62x16, Sealed
1235:-
25
T3500216
Circlip, Ext, 30.0, Din 471
40:-
26
T1183109
Gear, Output, 30t, Helical Fixed
2850:-
27
T1183102
Gear, Output, 39t, Helical, Free
2055:-
28
T1183075
Spacer, Plain, 31 x 45 x 19.85
315:-
29
T1183104
Gear, Output, 35t, Helical Fixed
1990:-
30
T1183060
Gear, Output, 43t, Helical
2975:-
31
T1183015
Spacer, Splined, Gearbox
1130:-
32
T1182020
Bush, 28.0 x 36.0 x 14.05
735:-
33
T1183050
Gear, Output, 47t, Helical
2975:-
34
T1182120
Spacer, 28.0 x 47.0 x 32.95
130:-
35
T1183112
Ring, Shift, 2nd/3rd Gear
6790:-
36
T1183080
Bush, 31.0 x 36.0 x 14.3
1180:-
37
T1184025
Retainer, M'cd, Bearing
385:-
38
T3600198
O-Ring, Dia. 72 x 2.5
105:-
39
T3205065
Bolt, HHF, Lghtd, M6 x 20, Enc, åtgår 4st
95:-
40
T3600182
Seal, Clockwise, 45 x 55 x 7, Oil
185:-
41
T1183020
Carrier, Pulley, Front, Splined
4285:-
42
T3600203
O Ring, ID 22.0 x 2.6
50:-
43
T1182240
Spacer, Tube, Plastic
105:-
44
T1182127
Nut, M20.0, Flanged
90:-
45
T1183200
Plate, Locking, Pulley Nut
75:-
46
T1180199
Output Pulley 28T, 32mm Belt
995:-
47
T3151009
Bolt, HHF, M12x1.75x30, Slv, Enc, åtgår 5st
120:-
48
T3551016
Washer, 20.45 x 40 x 2.0, Slv
45:-
